Adding a Border to and Image in My Code
Help, I Need to Put a Border on the Image Displayed from the Code Below. How Do I Do This? the Code Below Pulls up the Image, and Now I Need a Border. Help...
Help, I need to put a border on the image displayed from the code below. How do I do this? The code below pulls up the image, and now i need a border. Help.. All of this code is Python
# -*- coding: utf-8 -*-
'''
LoganCaroline_1_4_7: Merge images
'''
import matplotlib.pyplot as plt
import os.path
import numpy as np # “as” lets us use standard abbreviations
'''Read the image data'''
# Get the directory of this python script
directory = os.path.dirname(os.path.abspath(__file__))
# Build an absolute filename from directory + filename
filename = os.path.join(directory, 'family1.jpg')
# Read the image data into an array
img = plt.imread(filename)
'''Show the image data'''
# Create figure with 1 subplot
fig, ax = plt.subplots(1, 1)
# Show the image data in a subplot
ax.imshow(img, interpolation='none')
# Show the figure on the screen
fig.show()
1 Answer
Just create a slightly larger array that is black and fill the central pixels with your image.
import numpy as np
import matplotlib.pyplot as plt
def frame_image(img, frame_width):
b = frame_width # border size in pixel
ny, nx = img.shape[0], img.shape[1] # resolution / number of pixels in x and y
if img.ndim == 3: # rgb or rgba array
framed_img = np.zeros((b+ny+b, b+nx+b, img.shape[2]))
elif img.ndim == 2: # grayscale image
framed_img = np.zeros((b+ny+b, b+nx+b))
framed_img[b:-b, b:-b] = img
return framed_img
img = np.random.rand(456, 333, 3)
fig, (ax1, ax2) = plt.subplots(1,2)
ax1.imshow(img, interpolation='none')
ax2.imshow(frame_image(img, 20), interpolation='none')
plt.show()
