Adding Colors to Led Using Fastled
I Am Trying to Add Colors That I Set to an Led Using Fastled Library on Arduino Currently I Am Using Fill_Solid Like So, Leds(8 * Cluster, (8 * Cluster) +...
I am trying to add colors that I set to an led using FastLED library on arduino
Currently I am using fill_solid like so,
leds(8 * CLUSTER, (8 * CLUSTER) + (CLUSTER - 1)).fill_solid(CRGB(255,0 ,0));
FastLED.show();
However, I am not able to add colors to it after this has been set. Ideally I would like something like so,
leds(8 * CLUSTER, (8 * CLUSTER) + (CLUSTER - 1)).fill_solid(CRGB(255,0 ,0));
FastLED.show();
leds(8 * CLUSTER, (8 * CLUSTER) + (CLUSTER - 1)).fill_solid(CRGB(0,255 ,0));
FastLED.show();
And the led would glow with RGB = (255, 255, 0)
Is there any way to achieve this without keeping state information and just add to the existing color using FastLED?
2 Answers
leds(8 * CLUSTER, (8 * CLUSTER) + (CLUSTER - 1)) += CRGB(0,255,0); should do what you want (I’m pretty sure I checked that support in for the pixelviews)
leds is just an array of RGB values so you can just iterate through it with a for loop and modify the values. In this case += will work.
For example:
for (int i=0; i<NUM_LEDS; i++) leds[i] += CRGB(0,255,0);
