Arm Disassembly [Closed]
Is There a Tool Which Analyzes and Can Highlight What Each Line of Code Means. I Am Not Looking for a Decompiler Like That of Hex-Rays Decompiler. I Am Looking...
Is there a tool which analyzes and can highlight what each line of code means. I am not looking for a decompiler like that of Hex-Rays Decompiler. I am looking for a simple tool that shall be of assistance in reading the assembly code.
What about using objdump?
$ cat add.c
int add(int a, int b) {
return a + b;
}
$ arm-linux-gnueabihf-gcc -c -O2 add.c
$ arm-linux-gnueabihf-objdump -d add.o
add.o: file format elf32-littlearm
Disassembly of section .text:
00000000 <add>:
0: 1840 adds r0, r0, r1
2: 4770 bx lr
It can provide source code mixing as well if your object file contains debug information (gcc -g) and if you supply -S to objdump.
The Online Disassembler (ODA) supports ARM and a myriad of other architectures. You can enter binary data in the Live View and watch the disassembly appear as you type, or you can upload a file to disassemble. A nice feature of this site is that you can share the link to the disassembly with others.
As you mentioned in your question, IDA Pro can disassemble ARM too.
Besides, have you tried ARM DS-5 Development Studio?
Some features are more hardware-related, but the IDE (Eclipse) is very nice.
Features:
- Debug support for bare-metal, RTOS, Linux, and Android platforms
- Non-intrusive cycle-accurate ETM and PTM instruction tracing
- Seamless support for SMP systems
- Automated debug sessions for faster debug cycles
- ITM and STM instrumentation tracing
- Support for pre-configured and custom platforms
In the manual it says it contains:
- DS-5 Debugger, covering all stages of product development
- ARM Compiler 5.04 for embedded and bare-metal code
- Linaro GCC Toolchain 2013.03 for Linux applications and Linux kernel
- ARM Streamline™ Performance Analyzer for various operating systems, including Linux, Android and RTX
- Eclipse IDE, source code editor and project manager
- Fixed Virtual Platforms (FVP) for Cortex™-A8 and quad-core Cortex-A9 processors
- Example projects and documentation
What about this free program ::
