Aws Cloud Observability with Log Analytics

There are many types of logs in Amazon Web Services (AWS), and the more applications and services you run in AWS, the more complex your logging needs are bound to be. Logs originate from two primary sources—applications running on AWS services, and the AWS services themselves. An AWS centralized logging solution, therefore, becomes essential to manage this complexity. To achieve this kind of end-to-end visibility requires a conscious effort to centralize all the disparate logging data irrespective of their source of origin. AWS provides CloudWatch to centralize this data. CloudWatch is the primary collector that collects logs from different AWS services such as Amazon VPC Flow Logs, Route 53 Logs, Lambda Logs, CloudTrail Logs, and so on, in addition to log data from applications like Nginx or Apache system that you may be using in your AWS deployment.

Once collected in CloudWatch, you can use the BMC Helix Log Analytics solution to monitor and analyze logs and set up alerts. Doing this, you can get the native benefit of AWS log collection and the analytical power of the machine learning (ML)-powered observability platform provided by BMC. The ability to collect logs from CloudWatch allows you to aggregate all your log data combined with data from other sources across hybrid and multi-cloud environments. BMC Helix Log Analytics provides advanced monitoring and alerting capabilities to derive meaningful insights from logs, such as filtering by log metadata; enriching logs to add meaningful context; customizing alert messaging; automated alerting with ML-assisted anomaly detection; and service monitoring with BMC Helix Operations Management with artificial intelligence for IT operations (AIOps).

Centralized AWS logging with BMC Helix Log Analytics

The following diagram shows logs being collected from different applications and services across different AWS regions. CloudWatch collects logs by defining log streams and log groups for each region. A log stream is a sequence of log events coming from the application instance or resource being monitored. For example, a log stream may be associated with an Apache access log on a specific host. Log groups define groups of log streams that share the same retention, monitoring, and access control settings. One or more log streams belong to a log group. If you have a separate log stream for the Apache access logs from each host, you could group those log streams into a single log group called log.

Logs are aggregated in CloudWatch, and then collected and stored in BMC Helix Log Analytics for further analysis.

Collecting logs

BMC Helix Log Analytics uses a log collection policy to collect logs from AWS CloudWatch. To configure the collection policy, you must provide credentials to access the AWS account that contains the logs to be collected. Next, you would need to download and install the connector on the AWS platform to collect application or services logs for monitoring.

You may configure the refresh time and provide details of the region, log groups, and log streams for the logs to be collected.

You can also specify the application format to parse logs and provide log filters to include or exclude specific data. Log parsing helps to convert unstructured raw logs into meaningful key-value pairs and make them ready for analysis. It also enables you to get statistics on log message parameter values, conduct faceted searches, and filter logs by specific fields and values.

Once the configuration is done, you can see the health status of the log connector and policy configured to ensure there is no error with log collection. Then you can start to analyze logs in Explorer and create alerts and other policies as appropriate.
