Boost: :Flat_Map and Its Performance Compared to Map and Unordered_Map

I have run a benchmark on different data structures very recently at my company so I feel I need to drop a word. It is very complicated to benchmark something correctly.

Benchmarking

On the web, we rarely find (if ever) a well-engineered benchmark. Until today I only found benchmarks that were done the journalist way (pretty quickly and sweeping dozens of variables under the carpet).

1) You need to consider cache warming

Most people running benchmarks are afraid of timer discrepancy, therefore they run their stuff thousands of times and take the whole time, they just are careful to take the same thousand of times for every operation, and then consider that comparable.

The truth is, in the real world it makes little sense, because your cache will not be warm, and your operation will likely be called just once. Therefore you need to benchmark using RDTSC, and time stuff calling them once only. Intel has made a paper describing how to use RDTSC (using a cpuid instruction to flush the pipeline, and calling it at least 3 times at the beginning of the program to stabilize it).

2) RDTSC accuracy measure

I also recommend doing this:

u64 g_correctionFactor;  // number of clocks to offset after each measurement to remove the overhead of the measurer itself.
u64 g_accuracy;

static u64 const errormeasure = ~((u64)0);

#ifdef _MSC_VER
#pragma intrinsic(__rdtsc)
inline u64 GetRDTSC()
{
    int a[4];
    __cpuid(a, 0x80000000);  // flush OOO instruction pipeline
    return __rdtsc();
}

inline void WarmupRDTSC()
{
    int a[4];
    __cpuid(a, 0x80000000);  // warmup cpuid.
    __cpuid(a, 0x80000000);
    __cpuid(a, 0x80000000);

    // measure the measurer overhead with the measurer (crazy he..)
    u64 minDiff = LLONG_MAX;
    u64 maxDiff = 0;   // this is going to help calculate our PRECISION ERROR MARGIN
    for (int i = 0; i < 80; ++i)
    {
        u64 tick1 = GetRDTSC();
        u64 tick2 = GetRDTSC();
        minDiff = std::min(minDiff, tick2 - tick1);   // make many takes, take the smallest that ever come.
        maxDiff = std::max(maxDiff, tick2 - tick1);
    }
    g_correctionFactor = minDiff;

    printf("Correction factor %llu clocks\n", g_correctionFactor);

    g_accuracy = maxDiff - minDiff;
    printf("Measurement Accuracy (in clocks) : %llu\n", g_accuracy);
}
#endif

This is a discrepancy measurer, and it will take the minimum of all measured values, to avoid getting a -10**18 (64 bits first negatives values) from time to time.

Notice the use of intrinsics and not inline assembly. First inline assembly is rarely supported by compilers nowadays, but much worse of all, the compiler creates a full ordering barrier around inline assembly because it cannot static analyze the inside, so this is a problem to benchmark real-world stuff, especially when calling stuff just once. So an intrinsic is suited here because it doesn't break the compiler free-re-ordering of instructions.

3) parameters

The last problem is people usually test for too few variations of the scenario. A container performance is affected by:

1. Allocator
2. size of the contained type
3. cost of implementation of the copy operation, assignment operation, move operation, construction operation, of the contained type.
4. number of elements in the container (size of the problem)
5. type has trivial 3.-operations
6. type is POD

Point 1 is important because containers do allocate from time to time, and it matters a lot if they allocate using the CRT "new" or some user-defined operation, like pool allocation or freelist or other...

(for people interested about pt 1, join the mystery thread on gamedev about system allocator performance impact)

Point 2 is because some containers (say A) will lose time copying stuff around, and the bigger the type the bigger the overhead. The problem is that when comparing to another container B, A may win over B for small types, and lose for larger types.

Point 3 is the same as point 2, except it multiplies the cost by some weighting factor.

Point 4 is a question of big O mixed with cache issues. Some bad-complexity containers can largely outperform low-complexity containers for a small number of types (like map vs. vector, because their cache locality is good, but map fragments the memory). And then at some crossing point, they will lose, because the contained overall size starts to "leak" to main memory and cause cache misses, that plus the fact that the asymptotic complexity can start to be felt.

Point 5 is about compilers being able to elide stuff that are empty or trivial at compile time. This can optimize greatly some operations because the containers are templated, therefore each type will have its own performance profile.

Point 6 same as point 5, PODs can benefit from the fact that copy construction is just a memcpy, and some containers can have a specific implementation for these cases, using partial template specializations, or SFINAE to select algorithms according to traits of T.
