Cm Ports - Documentation for Bmc Client Management 12.6

Database connection *

Master Server

Database Server

TCP

TCP

Oracle: 1521 Postgres: 5432 SQL Server: 1433

For communication between the master server and the database. (* only if the database is on another server than the master)

Agent Rollout for Windows

Rollout Server

Client Devices

TCP

SMB

445,139

To install the CM agent on the Windows target devices.

To install the CM agent on the Unix target devices.

Client Agent communi-cation

Client Devices

Master Server

HTTP

1610, 1611

1610 is the default agent communication port. The connection must be bidirectional between the client and its parent for optimal settings. If it is unidirectional then it must be unidirectional from the client to the parent and in this case a tunnel on the port 1611 is used. The downwards direction can be replaced by a tunnel.

• If a client can be contacted by its parent, the tunnel is not required. When necessary, the parent connects to the client and calls one or more web services.

• If a client cannot be contacted by its parent, the tunnel is required. When tunnels are used by clients to communicate with their parent, the agent uses the 1611 port so it must be opened. It is created and monitored by the client and all the downstream communication occurs within. Note that this tunnel can be used for the upstream communication also, which is not mandatory (the parent is visible from the client so new transient TCP connections can be opened).

CM console

Administra-tive computer

Master Server and Client Devices

HTTP

1611 (1610)

The default console management port.

Bandwidth Throttling *

Relay

Client

TCP

TCP

1609

The bandwidth management port on relay servers. (* only used if transfer windows are defined with a percentage)

MyApps

1611 (1610)

The MyApps port on the master server.

AutoDiscovery

TCP

TCP, HTTP

135,22, 23,139, 1610

TCP ports scanned for auto-discovery.

Multicast Traffic

Relay

Client

UDP

UDP

2500 *

The multicast transfer agent listen port as configured. * An IP range must also be configured.

Active Directory LDAP

Master Server

LDAP Server

TCP

LDAP

389

To synchronize data from LDAP server to CM .

Email Server

Master Server, console

Email Server

TCP

SMTP

25

To send alerts and reports on email to users. This port must be open on all devices from which emails are sent via the console.

WebAPI

Browser, Web service caller

Master Server

TCP

HTTP

1616

The port for the web services.
