Control-M for Dbt - Documentation for Helix Control-M Integrations

The DBT (Data Build Tool) job is a cloud-based computing platform that enables you to develop, test, schedule, document, and analyze data models.

Control-M for DBT enables you to do the following:

• Connect to any DBT endpoint from a single computer with secure login, which eliminates the need to provide authentication.
• Integrate DBT jobs with other Control-M jobs into a single scheduling environment.
• Execute DBT jobs and override the predefined DBT job commands.
• Monitor the status, results, and output of DBT jobs in the Monitoring domain.
• Attach an SLA job to your DBT jobs.
• Introduce all Control-M capabilities to Control-M for DBT including advanced scheduling criteria, complex dependencies, Resource Pools, Lock Resources, and variables.
• Run 50 DBT jobs simultaneously per Agent.

Setting up Control-M for DBT

This procedure describes how to install the DBT plug-in, create a connection profile, and define a DBT job in Helix Control-M and Automation API.

Before you Begin

• Verify that Automation API is installed, as described in Setting up the API.
• Verify that Agent version 9.0.21.080 or later is installed.

Begin

1. On the Agent host, set the Java environment variable by running one of the following commands through a command line:

   • Linux:
     • Bourne shell/bash: export BMC_INST_JAVA_HOME=<java_11_directory>
     • csh/tcsh: setenv BMC_INST_JAVA_HOME <java_11_directory>
   • Windows:  set BMC_INST_JAVA_HOME="<java_11_directory>"
2. Run one of the following API commands:
   • For a fresh installation, use the provision image command:
     • Linux:  ctm provision image DBT_plugin.Linux
     • Windows: ctm provision image DBT_plugin.Windows
   • For an upgrade, use the following command:
     ctm provision agent::update
3. Create a DBT connection profile in Helix Control-M or Automation API, as follows:
4. Define a DBT job in Helix Control-M or Automation API, as follows:
