To create a survey questionnaire in PWA, perform the following tasks:
Before you begin
Make sure you have a basic understanding of the following:
Must Read
Task 1: Add a survey component definition in Developer Studio
Add a survey component definition in Developer Studio, which contains the mappings for the following system forms in Action Request System and a qualification. Based on this qualification, the questions and options are shown in the questionnaire.
| Form | Purpose |
|---|---|
| Question | The questions data is loaded from this form. |
| Options | The options for the selected questions are loaded from this form. |
| Response | The responses to the questions are stored in this form. |
Action Request System contains a system form called Survey Component Definition. An administrator can configure the Question form information, Option form information, and Response form information on this form. To configure all this information, the administrator must create a record on the Survey Component Definition form, from where all the questions, options, and responses are fetched. This record is displayed as a value in a list for the Component Definition property in Developer Studio.
Important
If you add a new entry to a system form, or modify an existing entry, you must re-login to Developer Studio for the changes to take effect.
For example, you can create the following entities:
- A record called Survey Questionnaire
- Three custom forms, namely Survey_Question, Survey_Option, and Survey_Response
- General fields, such as Question ID, Parent Entity ID, Question Label, Locale, and Company
Important
The Question ID field can be a unique identifier across all the three forms. The Parent Entity ID field is a record ID. The Parent Entity ID can be any custom ID.
To add a survey component definition:
- On a form in progressive view, drag the Survey Component field.
- On the Properties pane, expand the Display property group.
- Click the Component Definition property.
- In the Value column, select the record that you have already created.
