Do You Calibrate Ammeter?

To calibrate an ammeter, you need a 1 ohm reference shunt resistor

shunt resistor
Shunts are rated by the maximum current and voltage drop at that current. For example, a 500 A, 75 mV shunt would have a resistance of 150 microohm, a maximum allowable current of 500 amps and at that current the voltage drop would be 75 millivolts.
› wiki › Shunt_(electrical)
(or accurately measured shunt of low resistance) in series with the meter and measure the voltage drop across the shunt with a Potentiometer and calculate the current.

What other instrument can be used to calibrate an ammeter?

A potentiometer is a measuring device that can be used for measuring unknown resistance, voltage, and power in a circuit. Other than this a potentiometer application includes calibration of various measuring instruments like voltmeter, ammeter, and wattmeter.

Must Read

Do voltmeters need calibration?

All multimeters (multi-range instruments used to measure voltage, current, and resistance) are to be verified in calibration no less than once per year.
