Enable Ingress Controller on Docker Desktop with Wls2

You have to install an ingress-nginx controller on your cluster, so that your nodes will have an opened port 80/443.

Using helm (v3 - see documentation):

helm install --namespace kube-system nginx ingress-nginx --repo

Using kubectl (see documentation):

kubectl apply -f

Then manually adding your ingresses' hostnames to /etc/hosts:

127.0.0.1     ingress.local
127.0.0.1     my.other.service.local
# ...

Then if you make a request on :

• the DNS resolution will route to your cluster node
• then the ingress controller will serve the request on port 80
• then ingress will route the request to the configured backend service
• and the service will route to an available pod

The newest version of Docker Desktop for Windows already adds a hosts file entry: 127.0.0.1 kubernetes.docker.internal.

You had to do use kubernetes.docker.internal URL as a hostname in Ingress definition if you want to point to 127.0.0.1. This should be in the docs on this page but there is no Docker Desktop for Windows section there. Your files should look like this:

apiVersion: v1
kind: Service
metadata:
  name: webapp-service
spec:
  type: NodePort
  selector:
    app: webapp
  ports:
  - name: http
    protocol: TCP
    port: 3000
    nodePort: 30090

Your Ingress file should look like this:

apiVersion: extensions/v1beta1
kind: Ingress
metadata:
  name: webapp-ingress
spec:
  rules:
  - host: kubernetes.docker.internal
    http:
      paths:
      - path: /
        backend:
          serviceName: webapp-service
          servicePort: http

Then you are able to connect to app using .

Example you can see here: wsl2-docker-for-desktop.

I used the Docker-Desktop version to install the nginx-ingress controller

curl

Offcourse I've not installed any workload yet but the default ingress controller works just fine.

With Kustomize you can simply use

helmCharts:
  - name: ingress-nginx
    releaseName: ingress-nginx
    repo:

This is just to point out that Amel Mahmuzićs comment is still valid with a recent (I used the ingress-nginx Helm Chart 4.4.2) ingress deployment.

I could not get this to work for far too long (I tried to follow the Strapi fodadvisor example with Docker Desktop build in Kubernetes instead of minikube) and always received a 404 from the ingress.

However, after using this yaml with the added annotation

apiVersion:
kind: Ingress
metadata:
  name: main-ingress
  annotations:
     "nginx"
spec:
  rules:
  - host: foodadvisor.backend
    http:
      paths:
        - path: /
          pathType: Prefix
          backend:
            service:
              name: foodadvisor-backend
              port:
                number: 1337
  - host: foodadvisor.client
    http:
      paths:
        - path: /
          pathType: Prefix
          backend:
            service:
              name: foodadvisor-frontend
              port:
                number: 3000

it worked immediately. The K82 docs mention, that this annotation is deprecated.
