Expander Control in Wpf
I Need to Replace My Button Control from Below to Expander Control. I Don't Know How to Add Command to Expander Control, So When Expander Is Expanded I Would...
I need to replace my button control from below to Expander control.
<Button Grid.Row="14" Grid.ColumnSpan="2" Content="{Binding InspectionLayoutAdvancedButtonContent, Mode=OneWay}" HorizontalAlignment="Stretch" Margin="10,3" MinWidth="120"
Command="{Binding Path=AdvancedCommand}" Visibility="{Binding SelectedEditingLayoutViewModel.AdvancedButtonVisibility}"
CommandParameter="{Binding ElementName=gridAdvances}"/>
I don't know how to add Command to Expander control, so when Expander is expanded I would like to execute AdvancedCommand with parameter gridAdvanced.
How would be best way to implement this ?
Thanks.
4 Answers
Use the Expanded event:
<Expander Expanded="Expander_Expanded" />
and then call the command from the code behind:
private void Expander_Expanded(object sender, RoutedEventArgs e)
{
ViewModel vm = (ViewModel)DataContext;
if (vm.AdvancedCommand.CanExecute(vm.gridAdvances))
vm.AdvancedCommand.Execute(vm.gridAdvances));
}
Change ViewModel to whatever type your DataContext is.
Add a reference to System.Windows.Interactivity.dll (Project->Add Reference->Assemblies->Extensions in Visual Studio) and add an interaction trigger to the Expander:
<Expander xmlns:i="clr-namespace:System.Windows.Interactivity;assembly=System.Windows.Interactivity">
<i:Interaction.Triggers>
<i:EventTrigger EventName="IsExpanded" >
<i:InvokeCommandAction Command="{Binding AdvancedCommand}" CommandParameter="{Binding ElementName=gridAdvances}" />
</i:EventTrigger>
</i:Interaction.Triggers>
</Expander>
I suggest using the solution of mm8 with the event Expanded suggested by Freggar
<UserControl
xmlns:i="clr-amespace:System.Windows.Interactivity;assembly=System.Windows.Interactivity"/>
<Expander>
<i:Interaction.Triggers>
<i:EventTrigger EventName="Expanded" >
<i:InvokeCommandAction Command="{Binding AdvancedCommand}" CommandParameter="{Binding ElementName=gridAdvances}" />
</i:EventTrigger>
</i:Interaction.Triggers>
</Expander>
<UserControl>
I had the same problem, for some reason it is not possible to do simple an event trigger on attached property in the TreeView object (.net core 3 + wpf).
<i:Interaction.Triggers>
<i:EventTrigger EventName="Expander.Expand">
<i:InvokeCommandAction Command="{Binding MyCommand}"/>
</i:EventTrigger>
</i:Interaction.Triggers>
I had to solve it via custom behavior class.See below for inspiration ;)
public class TreeViewSelectionBehavior : Behavior<TreeView>
{
public object SelectedItem
{
get { return (object)GetValue(SelectedItemProperty); }
set { SetValue(SelectedItemProperty, value); }
}
public ICommand Command
{
get { return (ICommand)GetValue(CommandProperty); }
set { SetValue(CommandProperty, value); }
}
public static readonly DependencyProperty SelectedItemProperty =
DependencyProperty.Register("SelectedItem", typeof(object), typeof(TreeViewSelectionBehavior), new UIPropertyMetadata(null, OnSelectedItemChanged));
public static readonly DependencyProperty CommandProperty =
DependencyProperty.Register("Command", typeof(ICommand), typeof(TreeViewSelectionBehavior), null);
private static void OnSelectedItemChanged(DependencyObject sender, DependencyPropertyChangedEventArgs e)
{
var item = e.NewValue as TreeViewItem;
if (item != null)
{
item.SetValue(TreeViewItem.IsSelectedProperty, true);
}
}
protected override void OnAttached()
{
base.OnAttached();
this.AssociatedObject.SelectedItemChanged += OnTreeViewSelectedItemChanged;
this.AssociatedObject.AddHandler(TreeViewItem.ExpandedEvent, new RoutedEventHandler(this.Expanded));
}
private void Expanded(object sender, RoutedEventArgs e)
{
TreeViewItem item = e.OriginalSource as TreeViewItem;
if (this.Command.CanExecute(item))
{
this.Command.Execute(item);
}
}
protected override void OnDetaching()
{
base.OnDetaching();
if (this.AssociatedObject != null)
{
this.AssociatedObject.SelectedItemChanged -= OnTreeViewSelectedItemChanged;
this.AssociatedObject.RemoveHandler(TreeViewItem.ExpandedEvent, new RoutedEventHandler(this.Expanded));
}
}
private void OnTreeViewSelectedItemChanged(object sender, RoutedPropertyChangedEventArgs<object> e)
{
this.SelectedItem = e.NewValue;
}
}
Then usage is simple
<i:Interaction.Behaviors>
<local:TreeViewSelectionBehavior SelectedItem="{Binding SelectedItem}" Command="{Binding ExpandHistoricalItemCommand}"/>
</i:Interaction.Behaviors>
