Getting Readiness & Liveliness Probe Failed: Http Probe Failed with Statuscode: 503 During Starting of Varnish Using Helm Chart Kubernetes”
I Am Trying to Create a Helm Chart for Varnish to Be Deployed/Run on Kubernetes Cluster. While Running the Helm Package Which Has Varnish Image from Docker...
I am trying to create a Helm chart for varnish to be deployed/run on Kubernetes cluster. While running the helm package which has varnish image from Docker community its throwing error
Readiness probe failed: HTTP probe failed with statuscode: 503
Liveness probe failed: HTTP probe failed with statuscode: 503
Have shared values.yaml, deployment.yaml, varnish-config.yaml, varnish.vcl.
Any solution approached would be welcomed....
Values.yaml:
# Default values for tt.
# This is a YAML-formatted file.
# Declare variables to be passed into your templates.
replicaCount: 1
#vcl 4.0;
#import std;
#backend default {
# .host = "";
# .port = "80";
# .first_byte_timeout = 60s;
# .connect_timeout = 300s;
#}
varnishBackendService: ""
varnishBackendServicePort: "80"
image:
repository: varnish
tag: 6.0.6
pullPolicy: IfNotPresent
nameOverride: ""
fullnameOverride: ""
service:
type: ClusterIP
port: 80
#probes:
# enabled: true
ingress:
enabled: false
annotations: {}
# nginx
# "true"
path: /
hosts:
- chart-example.local
tls: []
# - secretName: chart-example-tls
# hosts:
# - chart-example.local
resources:
limits:
memory: 128Mi
requests:
memory: 64Mi
#resources: {}
# We usually recommend not to specify default resources and to leave this as a conscious
# choice for the user. This also increases chances charts run on environments with little
# resources, such as Minikube. If you do want to specify resources, uncomment the following
# lines, adjust them as necessary, and remove the curly braces after 'resources:'.
# limits:
# cpu: 100m
# memory: 128Mi
# requests:
# cpu: 100m
# memory: 128Mi
nodeSelector: {}
tolerations: []
affinity: {}
Deployment.yaml:
apiVersion: apps/v1beta2
kind: Deployment
metadata:
name: {{ include "varnish.fullname" . }}
labels:
app: {{ include "varnish.name" . }}
chart: {{ include "varnish.chart" . }}
release: {{ .Release.Name }}
heritage: {{ .Release.Service }}
spec:
replicas: {{ .Values.replicaCount }}
selector:
matchLabels:
app: {{ include "varnish.name" . }}
release: {{ .Release.Name }}
template:
metadata:
labels:
app: {{ include "varnish.name" . }}
release: {{ .Release.Name }}
# annotations:
# "true"
spec:
volumes:
- name: varnish-config
configMap:
name: {{ include "varnish.fullname" . }}-varnish-config
items:
- key: default.vcl
path: default.vcl
containers:
- name: {{ .Chart.Name }}
image: "{{ .Values.image.repository }}:{{ .Values.image.tag }}"
imagePullPolicy: {{ .Values.image.pullPolicy }}
env:
- name: VARNISH_VCL
value: /etc/varnish/default.vcl
volumeMounts:
- name: varnish-config
mountPath : /etc/varnish/
ports:
- name: http
containerPort: 80
protocol: TCP
targetPort: 80
livenessProbe:
httpGet:
path: /healthcheck
port: http
port: 80
failureThreshold: 3
initialDelaySeconds: 45
timeoutSeconds: 10
periodSeconds: 20
readinessProbe:
httpGet:
path: /healthcheck
port: http
port: 80
initialDelaySeconds: 10
timeoutSeconds: 15
periodSeconds: 5
restartPolicy: "Always"
resources:
{{ toYaml .Values.resources | indent 12 }}
{{- with .Values.nodeSelector }}
nodeSelector:
{{ toYaml . | indent 8 }}
{{- end }}
{{- with .Values.affinity }}
affinity:
{{ toYaml . | indent 8 }}
{{- end }}
{{- with .Values.tolerations }}
tolerations:
{{ toYaml . | indent 8 }}
{{- end }}
vanrnish-config.yaml:
apiVersion: v1
kind: ConfigMap
metadata:
name: {{ template "varnish.fullname" . }}-varnish-config
labels:
app: {{ template "varnish.fullname" . }}
chart: "{{ .Chart.Name }}-{{ .Chart.Version }}"
release: "{{ .Release.Name }}"
heritage: "{{ .Release.Service }}"
data:
default.vcl: |-
{{ $file := (.Files.Get "config/varnish.vcl") }}
{{ tpl $file . | indent 4 }}
varnish.vcl:
# VCL version 5.0 is not supported so it should be 4.0 or 4.1 even though actually used Varnish version is 6
vcl 4.1;
import std;
# The minimal Varnish version is 5.0
# For SSL offloading, pass the following header in your proxy server or load balancer: 'X-Forwarded-Proto: https'
backend default {
#.host = "{{ default "google.com" .Values.varnishBackendService }}";
.host = "{{ .Values.varnishBackendService }}";
.port = "{{ .Values.varnishBackendServicePort }}";
#.port = "{{ default "80" .Values.varnishBackendServicePort }}";
.first_byte_timeout = 60s;
.connect_timeout = 300s ;
.probe = {
.url = "/";
.timeout = 1s;
.interval = 5s;
.window = 5;
.threshold = 3;
}
}
backend server2 {
.host = "74.125.24.105:80";
.probe = {
.url = "/";
.timeout = 1s;
.interval = 5s;
.window = 5;
.threshold = 3;
}
}
import directors;
sub vcl_init {
new vdir = directors.round_robin();
vdir.add_backend(default);
vdir.add_backend(server2);
}
#sub vcl_recv {
# if (req.url ~ "/healthcheck"){
# error 200 "imok";
# set req.http.Connection = "close";
# }
#}
1 Answer
The fact that Kubernetes returns an HTTP 503 error for both the readiness & the liveliness probes means that there's probably something wrong with the connection to your backend.
Interestingly, that's besides the point. Those probes aren't there to perform an end-to-end test of your HTTP flow. The probes are only there to verify if the service they are monitoring is responding.
That's why you can just return a synthetic HTTP response when capturing requests that point to /healthcheck.
Here's the VCL code to do it:
sub vcl_recv {
if(req.url == "/healthcheck") {
return(synth(200,"OK"));
}
}
That doesn't explain the fact why you're getting an HTTP 503 error, but at least, the probes will work.
