Getting Soc4 Abend in a Cobol File Program
I Am Writing Cobol Pgm to Sum 2 Numbers, Passing These 2 Numbers from Jcl in an Input File and Storing Their Sum in Output File. but I Am Getting Soc4 (At...
I am writing COBOL pgm to sum 2 numbers, passing these 2 numbers from JCL in an input file and storing their sum in output file. But I am getting SOC4 (at MOVE). Below is my code. Please advise
ENVIRONMENT DIVISION.
INPUT-OUTPUT SECTION.
FILE-CONTROL.
SELECT FILEIN ASSIGN TO INPFILE
ORGANIZATION IS SEQUENTIAL
ACCESS MODE IS SEQUENTIAL
FILE STATUS IS WS-ST1.
SELECT FILEOUT ASSIGN TO OUTFILE
ORGANIZATION IS SEQUENTIAL
ACCESS MODE IS SEQUENTIAL
FILE STATUS IS WS-ST2.
DATA DIVISION.
FILE SECTION.
FD FILEIN.
01 FIN-REC.
05 FIN-NUM1 PIC 9(2).
05 FILLER PIC X(1).
05 FIN-NUM2 PIC 9(2).
05 FILLER PIC X(75).
FD FILEOUT.
01 FOUT-TOT PIC 9(2).
01 FILLER PIC X(78).
WORKING-STORAGE SECTION.
01 WS-REC.
05 WS-NUM1 PIC 9(2).
05 WS-NUM2 PIC 9(2).
01 WS-ST1 PIC X(2) VALUE SPACES.
01 WS-ST2 PIC X(2) VALUE SPACES.
01 WS-EOF PIC X(1) VALUE SPACE.
01 WS-SUM PIC 9(2).
PROCEDURE DIVISION.
MAIN-PARA.
PERFORM 100-INITIAL-PARA THRU 100-EXIT.
PERFORM 200-PROCESS-PARA THRU 200-EXIT
UNTIL WS-EOF='Y'.
PERFORM 300-COMPUTE-PARA THRU 300-EXIT.
PERFORM 400-WRITE-PARA THRU 400-EXIT.
STOP RUN.
100-INITIAL-PARA.
MOVE 'N' TO WS-EOF
OPEN INPUT FILEIN
IF WS-ST1 NOT = '00'
DISPLAY 'ERROR IN 100-INITIAL-PARA'
DISPLAY 'INPUT FILE OPEN STATUS IS' WS-ST1
DISPLAY 'OUTPUT FILE OPEN STATUS IS' WS-ST2
END-IF.
100-EXIT.
EXIT.
200-PROCESS-PARA.
PERFORM UNTIL WS-EOF='Y'
READ FILEIN INTO WS-REC
AT END MOVE 'Y' TO WS-EOF
NOT AT END DISPLAY WS-REC
END-READ
END-PERFORM
CLOSE FILEIN.
200-EXIT.
EXIT.
300-COMPUTE-PARA.
COMPUTE WS-SUM= WS-NUM1 + WS-NUM2.
300-EXIT.
EXIT.
400-WRITE-PARA.
OPEN OUTPUT FILEOUT.
MOVE WS-SUM TO FOUT-TOT.
*> SOC4 abend in MOVE above
WRITE FOUT-TOT
END-WRITE.
CLOSE FILEOUT.
400-EXIT.
EXIT.
Below is the run JCL
//A102153J JOB MSGCLASS=S,MSGLEVEL=(1,1),NOTIFY=&SYSUID,REGION=0M
//STEP001 EXEC PGM=EXER4
//STEPLIB DD DISP=SHR,DSN=ADESH.LOADLIB
//INPFILE DD DSN=ADESH.EXER4.INFILE,DISP=SHR
//OUTFILE DD DSN=ADESH.EXER4.OUTFILE,UNIT=SYSDA,
// DISP=(NEW,CATLG,DELETE),SPACE=(CYL,(1,1),RLSE),
// DCB=(RECFM=FB,LRECL=80,BLKSIZE=0)
//SYSOUT DD SYSOUT=*
//SYSPRINT DD SYSOUT=*
2 Answers
Problem could be the output declaration:
FD FILEOUT.
01 FOUT-TOT PIC 9(2).
01 FILLER PIC X(78).
Replace with
FD FILEOUT.
01 out-record.
03 FOUT-TOT PIC 9(2).
03 FILLER PIC X(78).
Also update the write to
Write out-record.
Reason for the problem is the 2 01 levels --> VB which is different to the FB definition in the JCL which will cause the open to fail
There are a couple of logic errors in you program.
Firstly, in
100-INITIAL-PARA.
MOVE 'N' TO WS-EOF
OPEN INPUT FILEIN
IF WS-ST1 NOT = '00'
DISPLAY 'ERROR IN 100-INITIAL-PARA'
DISPLAY 'INPUT FILE OPEN STATUS IS' WS-ST1
DISPLAY 'OUTPUT FILE OPEN STATUS IS' WS-ST2
END-IF.
You open the input file, only, but check (well display) the status of the output file, which is yet to be opened.
Secondly, in the main paragraph
MAIN-PARA.
...
PERFORM 200-PROCESS-PARA THRU 200-EXIT
UNTIL WS-EOF='Y'.
you code a repetitive loop to end at end of input. And the called section
200-PROCESS-PARA.
PERFORM UNTIL WS-EOF='Y'
READ FILEIN INTO WS-REC
AT END MOVE 'Y' TO WS-EOF
NOT AT END DISPLAY WS-REC
END-READ
END-PERFORM
CLOSE FILEIN.
200-EXIT.
EXIT.
is again a repetitive loop to end at end of input file. There is one loop to many here.
Thirdly, in the section to write the output, you open the output file but are missing to check the status thereafter.
400-WRITE-PARA.
OPEN OUTPUT FILEOUT.
MOVE WS-SUM TO FOUT-TOT.
WRITE FOUT-TOT
END-WRITE.
CLOSE FILEOUT.
400-EXIT.
EXIT.
Lastly, the sum of two two digit numbers may well become a three digit number. You sum fields are declared as 2 digit field, however.
