Golang: How to Simulate Union Type Efficiently

You can use arrays to represent a single int32 as two int16s and then assemble them with shifts as Rob Pike recommends:

func test3() (total int64) {
    type A struct {
        t int32
        u [2]int16
    }
    a := [...]A{
        {1, [2]int16{100, 0}},
        {2, [2]int16{3, 0}},
    }

    for i := 0; i < N; i++ {
        p := &a[i%2]
        switch p.t {
        case 1:
            total += int64(p.u[0]<<0 | p.u[1]<<8)
        case 2:
            total += int64(p.u[0])
        }
    }
    return
}

With the original Go compiler it runs about 2 times slower than the C version, and with gccgo (-O3) it runs about as fast as C.

Be warned though that this approach assumes little-endian ints. You'll need to switch the order of shifts for big-endian architecture.

Also, if you need to decode structures from a byte slice, you should really be using encoding/binary. This library is created to translate between byte sequences and other types.

I bet myself to make it much closer to C variant, and here's what I got:

(full code)

thing is that we going through all struct's fields and redirect them to buffer's storage (which has compile-time len refereed from template struct, for sake of memory salvation and universality)

result:

func test() (total int64) {

    type A struct {
        t int32
        u struct {
            // embedded buffer of union
            FooSize

            // mark all types inside as pointer types
            i *int32 // long
            v *int16 //short
        }
    }
    var a [2]A

    // initialize them
    Union(&a[0].u)
    Union(&a[1].u)

    a[0].t = 1
    *a[0].u.i = 100
    a[1].t = 2
    *a[1].u.v = 3

    for c := 0; c < 5000000000; c++ {
        p := &a[c%2]
        switch p.t {
        case 1:
            total += int64(*p.u.i)
        case 2:
            total += int64(*p.u.v)
        }
    }

    return
}

// your bench:

257500000000
8.111239763s

// native bench (8,18800064s):

BenchmarkUnion         1        8188000640 ns/op              80 B/op          1 allocs/op

Ran it on $5 digitalocean droplet.

Implementation is cursed and may be not compatible with future versions of Go (current is 1.13), but usage (as behavior) is C-like, also supports any type (you can replace integers with structs as well)

The union may contains numeric types and octet string, so I try to use byte slice as the value container and use unsafe.Pointer to access it according to the concrete type.

func test3() (total int64) {
    type A struct {
        t int32
        u []byte
    }

    a := [...]A{{1, make([]byte, 8)}, {2, make([]byte, 8)}}
    *(*int32)(unsafe.Pointer(&a[0].u)) = 100
    *(*int16)(unsafe.Pointer(&a[1].u)) = 3

    for i := 0; i < 5000000000; i++ {
        p := &a[i%2]
        switch p.t {
        case 1:
            total += int64(*(*int32)(unsafe.Pointer(&p.u)))
        case 2:
            total += int64(*(*int16)(unsafe.Pointer(&p.u)))
        }
    }
    return
}

result:

$ go run union.go
257500000000
12.844752701s

$ go run -compiler gccgo -gccgoflags -O3 union.go
257500000000
6.640667s

Is it the best version?

I wrote a small tool to generate C-style unions called unionize which you can find at . You give it a template and then it will generate Go code that acts like a union and has comparable performance to C (warning: it uses the unsafe package, see the github repository for how it works and a detailed discussion of alternatives).

I copied your C benchmark into Go using unionize. First create a template for the union, for example in union.go:

package main

type Int struct {
    i int32
    v int16
}

Now use unionize to generate the actual union code which will go into a_union.go:

$ unionize -output=a_union.go Int union.go

This creates a new type IntUnion from the Int template which exposes functions to manipulate the union members. Now we can write the benchmark using that type:

package main

import "fmt"

type A struct {
    t int
    u IntUnion
}

func main() {
    var a [2]A
    a[0].t = 1
    a[0].u.iPut(100)
    a[1].t = 2
    a[1].u.vPut(3)

    var total int
    for i := 0; i < 5000000000; i++ {
        p := &a[i%2]
        switch p.t {
        case 1:
            total += int(p.u.i())
        case 2:
            total += int(p.u.v())
        }
    }

    fmt.Println(total)
}

When I time it I get:

$ go build main.go a_union.go
$ time ./main
257500000000

real    0m6.202s
user    0m6.197s
sys 0m0.012s

Not bad! (on my machine the C benchmark runs in roughly 3 seconds). The tool is fairly small, so let me know if there are more features you are looking for, or if you find any bugs.

Here is a solution which stores the union data as an interface{} and then uses a type switch to decide which data is stored in the union field:

package main

import "fmt"

type A struct {
    u interface{}
}

func test() int64 {
    a := []A{
        {u: int32(100)},
        {u: int16(3)},
    }

    total := int64(0)
    for i := int64(0); i < 5000000000; i++ {
        switch x := a[i%2].u.(type) {
        case int32:
            total += int64(x)
        case int16:
            total += int64(x)
        }
    }
    return total
}

func main() {
    total := test()
    fmt.Println(total)
}

Due to the use of the type switch, the field t is not needed, making the code a bit tidier than the C version. This is still slower than the C code, but only by a factor of two.

C version:

257500000000

real    0m3.788s
user    0m3.776s
sys 0m0.011s

Go version:

257500000000

real    0m6.229s
user    0m6.211s
sys 0m0.019s
