How Do I Combine Two Plots into One Figure Using Plotly?
I Have 2 Csv Files, My Codes Are as Below. Df = Pd. Read_Csv("Test. Csv", Sep='\T', Skiprows=Range(9), Names=['A', 'B', 'C','D']) Df2 = Pd...
I have 2 csv files, my codes are as below.
df = pd.read_csv("test.csv",
sep='\t',skiprows=range(9),names=['A', 'B', 'C','D'])
df2 = pd.read_csv("LoadMatch_Limit.csv",skiprows=range(1),names=['X','Y'])
fig = px.line([df,df2], x=['A','X'] , y=['D','Y'])
I would like my line chart, x-axis to take from (columns 'A' and 'X') and my y-axis to take from (columns 'D' and 'Y'). Is there anyway I can plot these 2 charts as one figure?
2 Answers
You could create the two plots and combine them with plotly graph objects
import plotly.express as px
import plotly.graph_objects as go
fig1 = px.line(df, x='A', y='D')
fig2 = px.line(df2, x='X', y='Y')
fig = go.Figure(data = fig1.data + fig2.data)
fig.show()
Plotly.offline has no attribute line. You need to use the graph object to plot two graphs in a single figure. A simple example is shown below(run the code below and see the output graph)
import numpy as np
import pandas as pd
import plotly.offline as py
import plotly.graph_objs as go
from plotly import tools
df1 = pd.DataFrame({"X":np.linspace(0,30,10), "Y":np.random.rand(10)})
df2 = pd.DataFrame({"A":np.linspace(0,40,10), "B":np.random.rand(10)})
# plotting the graphs...
# 'rgb(128, 0, 128)'
# color=sns.color_palette()
def scatter_chart(x, y, color, name):
trace = go.Scatter(
x=x.values,
y=y.values,
name=name,
marker=dict(
color=color,
line=dict(
color=color,
width=1)
),
)
return trace
trace1 = scatter_chart(df2["A"], df2["B"], 'rgb(128, 0, 128)', "df2")
trace2 = scatter_chart(df1["X"], df1["Y"], 'rgba(50, 171, 96, 0.6)', "df1")
fig = tools.make_subplots(rows=1,cols=1, vertical_spacing=0.5)
fig.add_trace(trace1)
fig.add_trace(trace2)
fig.update_layout(
title="df2 and df1 plot",
height=600,
width=600,
# annotations=annotations,
xaxis=dict(tickangle=-45),
legend=dict(x=0.029, y=1.038, font_size=10),
margin=dict(l=100, r=20, t=70, b=70),
paper_bgcolor='rgb(248, 248, 255)',
plot_bgcolor='rgb(248, 248, 255)',)
py.iplot(fig, filename='pageviews_plots_4')
