How Do I Know What Size Ring Gear My Ford Has?
Measure the Diameter of the Ringgear. This Measurement Equals the Size of Your Rear End. Count How Many Bolts Are on the Inspection Cover. If Youhave 10 Bolts...
.
In this manner, how do I know what size ring gear I have?
The ring gear diameter is measured across theface of the gear. To obtain the ring gear diameter,simply place a tape measurer across the gear. This can betricky if the ring gear & carrier are still in thehousing. In some cases, a differential can be identified by thenumber of cover bolts is has.
One may also ask, what is a 9 rear end? The center section of the 9 inch rear endis removable allowing you to swap gears or differentials on abench. Nine inch Ford rear ends came in many widths andconfigurations. Depending on the application, the rear endmay be heavier duty, be made of high performance materials or havea locking differential.
Also Know, how do you measure a differential?
To measure the ring gear diameter, the inside ofthe differential unit must be accessed, which can be done byopening either the rear inspection cover or by removing the axleand cover on the forward face of the housing, depending on thedifferential type.
How many bolts does a Ford 9 inch have?
Not all drop-out Ford rearends are9-inch units. The easiest way to identify them is byexamining the two lowest gear-case bolts.
How do I know what size rear end I have?
How do you measure a rear end?
- Locate the axle flanges on either side of the rear axle. Theflange is the platform on which the wheels are mounted and boltedto the axle.
- Using a measuring tape, measure from one flange to the other.To ensure an accurate measurement, always measure from end to endwhere the wheels bolt on to the axle.
