Generally accepted practice for sizing piping for pneumatic systems is to use a pressure drop of 10% of gage for nominal pipe sizes up to and including 1/2″, and 5% of gage for nominal pipe sizes of 3/4″ and larger.
How do I calculate air pipe size?
Typically, you can multiply the capacity of straight-line piping by 1.5 for loop type compressed air distribution systems. For example: If a 2” aluminum pipe is rated for 500 CFM at 125 PSI, that same length of pipe in a loop system would be rated for 750 CFM at 125 PSI.
How do you calculate CFM of an air line?
Start with the total volume of air (in cubic feet), divide by the exchange rate (how quickly you want to replace the air), and the result is the total CFM you need for your system.
