I got this class to compute the CRC8 checksum of a byte[]:
public static class Crc8
{
static byte[] table = new byte[256];
// x8 + x7 + x6 + x4 + x2 + 1
const byte poly = 0xd5;
public static byte ComputeChecksum(params byte[] bytes)
{
byte crc = 0;
if (bytes != null && bytes.Length > 0)
{
foreach (byte b in bytes)
{
crc = table[crc ^ b];
}
}
return crc;
}
static Crc8()
{
for (int i = 0; i < 256; ++i)
{
int temp = i;
for (int j = 0; j < 8; ++j)
{
if ((temp & 0x80) != 0)
{
temp = (temp << 1) ^ poly;
}
else
{
temp <<= 1;
}
}
table[i] = (byte)temp;
}
}
}
And in the Main I got:
static void Main(string[] args)
{
string number = "123456789";
Console.WriteLine(Convert.ToByte(Crc8.ComputeChecksum(StringToByteArray(number))).ToString("x2"));
Console.ReadLine();
}
private static byte[] StringToByteArray(string str)
{
ASCIIEncoding enc = new ASCIIEncoding();
return enc.GetBytes(str);
}
This results in 0xBC
However, according to: this is incorrect, because the checksum for the CheckSum8 Xor is 0x31.
What did I wrong there?
2 Answers
On the linked site only some 16 and 32 bit CRCs are listed, the CheckSum8Xor is not a CRC. The 0xBC comes from a 8-bit CRC called "CRC-8/DVB-S2", see
Ah, ok, so I've overiterpreted this checksum computation.
Well, in that case, it's easy:
public static byte Checksum8XOR(byte[] data)
{
byte checksum = 0x00;
for (int i = 0; i < data.Length; i++)
{
checksum ^= data[i];
}
return checksum;
}
