Jetty Ssl Factory Using Http2 Doesn't Work
I Have a Simple Spring Boot Project Using Jetty. I Run on Port 443 and Use Http1.1 Just Fine @Bean(Name = "Containercustomizer") Public...
I have a simple spring boot project using jetty.
I run on port 443 and use http1.1 just fine
@Bean(name = "containerCustomizer")
public WebServerFactoryCustomizer containerCustomizer()
{
return (container -> ((JettyServletWebServerFactory) container).addServerCustomizers(server -> {
// HTTPS
SslContextFactory.Server sslContextFactory = new SslContextFactory.Server();
sslContextFactory.setKeyStoreResource(Resource.newResource(
getClass().getClassLoader().getResource("keystore.jks")));
sslContextFactory.setKeyStorePassword("password");
sslContextFactory.setProtocol("TLS");
sslContextFactory.setKeyStoreType("JKS");
HttpConfiguration https = new HttpConfiguration();
https.addCustomizer(new SecureRequestCustomizer());
SslConnectionFactory sslFactory = new SslConnectionFactory(sslContextFactory,
HttpVersion.HTTP_1_1.asString());
ServerConnector sslConnector = new ServerConnector(server, sslFactory, new HttpConnectionFactory(https));
sslConnector.setPort(443);
server.setConnectors(new Connector[] {sslConnector});
}));
}
However once I change to HTTP2 by replacing HttpVersion.HTTP_1_1.asString() with HttpVersion.HTTP_2.asString() then I get exception
Caused by: java.lang.IllegalStateException: No protocol factory for SSL next protocol: 'HTTP/2.0' in ServerConnector@61e45f87{SSL, (ssl, http/1.1)}{0.0.0.0:443}
at org.eclipse.jetty.server.AbstractConnector.doStart(AbstractConnector.java:317) ~[jetty-server-9.4.35.v20201120.jar:9.4.35.v20201120]
at org.eclipse.jetty.server.AbstractNetworkConnector.doStart(AbstractNetworkConnector.java:81) ~[jetty-server-9.4.35.v20201120.jar:9.4.35.v20201120]
at org.eclipse.jetty.server.ServerConnector.doStart(ServerConnector.java:234) ~[jetty-server-9.4.35.v20201120.jar:9.4.35.v20201120]
at org.eclipse.jetty.util.component.AbstractLifeCycle.start(AbstractLifeCycle.java:73) ~[jetty-util-9.4.35.v20201120.jar:9.4.35.v20201120]
at org.springframework.boot.web.embedded.jetty.JettyWebServer.start(JettyWebServer.java:174) ~[spring-boot-2.3.7.RELEASE.jar:2.3.7.RELEASE]
... 16 common frames omitted
1 Answer
Just changing the version string isn't sufficient.
You'll also need ...
ALPNServerConnectionFactory- for processing the TLS layer (known as ALPN) that selects the HTTP/2 protocolHTTP2ServerConnectionFactory- for using HTTP/2 protocol
As seen in the embedded / Http2Server.java example
The key is that you will chain the connection types together, ALPN to HTTP2 to HTTPS.
// SSL Context Factory for HTTPS and HTTP/2
SslContextFactory sslContextFactory = new SslContextFactory.Server();
// configure sslContextFactory
// HTTPS Configuration
HttpConfiguration httpsConfig = new HttpConfiguration(httpConfig);
httpsConfig.addCustomizer(new SecureRequestCustomizer());
// HTTP/2 Connection Factory
HTTP2ServerConnectionFactory h2 = new HTTP2ServerConnectionFactory(httpsConfig);
ALPNServerConnectionFactory alpn = new ALPNServerConnectionFactory();
alpn.setDefaultProtocol(http.getDefaultProtocol());
// SSL Connection Factory
SslConnectionFactory ssl = new SslConnectionFactory(sslContextFactory, alpn.getProtocol());
// HTTP/2 Connector
ServerConnector http2Connector =
new ServerConnector(server, ssl, alpn, h2, new HttpConnectionFactory(httpsConfig));
http2Connector.setPort(securePort);
server.addConnector(http2Connector);
