Json Representation of Map with Complex Key

You don't need annotations or custom serializers. Assuming you already have getters for all the fields in Part and Machine, all that's really missing is a toString() on PartDescriptor. If, for some reason, you don't have getter functions, you'll need to annotate the fields of interest with @JsonProperty so Jackson knows which fields to include in the serialized output. However, it's preferable (and easier) to simply create getters.

The toString() on PartDescriptor should return the key you want to use in your mapping. As another answer suggests, you might simply concatenate the relevant fields:

@Override
public String toString() {
    return group + "|" + id;
}

Then you'll magically get this form when you attempt to serialize a Machine with Jackson's ObjectMapper:

{
  "name" : "Toaster",
  "parts" : {
    "Electrical|Descriptor1" : {
      "group" : "Electrical",
      "id" : "Part1",
      "description" : "Heating Element",
      "compat" : "B293"
    },
    "Exterior|Descriptor2" : {
      "group" : "Exterior",
      "id" : "Part2",
      "description" : "Lever",
      "compat" : "18A"
    }
  }
}

I would do this. The parts key of the top level object would be a JSONArray of JSONObject that have key's and value's. The key would be an object that is your PartDescriptor and the value would be your Part.

{
    "name":"theName",
    "parts":[
        {
            "key":{
                       "group":"theGroup",
                       "id":"theId"
                  },
            "value":{
                       "group":"theGroup",
                       "id":"theId",
                       "description":"theDescription",
                       "compat":"theCompat",
                       ...
                    }
        },
        ...
    ]
}

Assuming that group+id gives a unique combination, and that ":" is a permissible delimiter:

{
   "name": "machine name",
   "parts": {
               "somegroup:01465": {
                                    "group":"somegroup",
                                    "id": "01465",
                                    ...
                                  },
               "othergroup:32409": {
                                     "group":"othergroup",
                                     "id": "32409",
                                     ...
                                   }

            }
}

JSON requires the key to be a string, so if you truly need the data to be represented as keyed (e.g. you don't want to use an array, like in Pointy's answer, because you'd like to guarantee it in the contract that there are no duplicate entries with the same key) then you'd need to decide yourself on a way to serialize the complex key into a string.

Two things to note if going with an approach that uses concatenating with a separator (e.g. group1|part1):

• You'll want a separator that cannot itself occur in the key parts, or you'll need to escape it when serializing (e.g. double it). The problems that this prevents might be rare to run into, but if this is to be written in a reusable, general purpose code, it should better be guaranteed, as per Murphy's law - if something can go wrong, it eventually will.
• To truly prevent 'more than one value with same compound key', you'll want to maintain the same order of the keys, e.g. sort the key alphabetically

Whereas re:

Also (optional), point me to a JSON to Java serializer/deserializer that will support your representation

One notable example might be Gson - Google's JSON serializer library for Java - which uses this representation:

{
     "(group1,part1)": { description: ... },
     "(group1,part2)": { description: ... },
     "(group2,part1)": { description: ... },
     ...
     "(groupX,partX)": {description: ... },
}

Note: the feature needs to be enabled by setting enableComplexMapKeySerialization (off by default for backwards compatibility)
