Making a Control Transparent

Question

I am currently developing a simple image editing tool using Winforms and .NET 3.5 (work environment).

I have a requirement that when the user clicks a select tool button, a square (rectangle in C#) will appear that they can scale between 100x100 and 400x400. I have this bit fixed - the issue comes with making the background of the rectangle transparent.

I'm a little unclear on if transparency is supported in .NET 3.5, I've tried the following:

SetStyle(ControlStyles.SupportsTransparentBackColor, true);
pnlSelectArea.BackColor = Color.Transparent;
pnlSelectArea.ForeColor = Color.Transparent;
selectArea1.BackColor = Color.Transparent;
selectArea1.ForeColor = Color.Transparent;

But this has no effect - any advice would be appreciated.

Accepted Answer

This is my special Control which contains an opacity property, it 100% works:

using System;
using System.Collections;
using System.ComponentModel;
using System.ComponentModel.Design;
using System.Drawing;
using System.Windows.Forms;
using System.Windows.Forms.Design;

public class TranspCtrl : Control
{
    public bool drag = false;
    public bool enab = false;
    private int m_opacity = 100;

    private int alpha;
    public TranspCtrl()
    {
        SetStyle(ControlStyles.SupportsTransparentBackColor, true);
        SetStyle(ControlStyles.Opaque, true);
        this.BackColor = Color.Transparent;
    }

    public int Opacity
    {
        get
        {
            if (m_opacity > 100)
            {
                m_opacity = 100;
            }
            else if (m_opacity < 1)
            {
                m_opacity = 1;
            }
            return this.m_opacity;
        }
        set
        {
            this.m_opacity = value;
            if (this.Parent != null)
            {
                Parent.Invalidate(this.Bounds, true);
            }
        }
    }

    protected override CreateParams CreateParams
    {
        get
        {
            CreateParams cp = base.CreateParams;
            cp.ExStyle = cp.ExStyle | 0x20;
            return cp;
        }
    }

    protected override void OnPaint(PaintEventArgs e)
    {
        Graphics g = e.Graphics;
        Rectangle bounds = new Rectangle(0, 0, this.Width - 1, this.Height - 1);

        Color frmColor = this.Parent.BackColor;
        Brush bckColor = default(Brush);

        alpha = (m_opacity * 255) / 100;

        if (drag)
        {
            Color dragBckColor = default(Color);

            if (BackColor != Color.Transparent)
            {
                int Rb = BackColor.R * alpha / 255 + frmColor.R * (255 - alpha) / 255;
                int Gb = BackColor.G * alpha / 255 + frmColor.G * (255 - alpha) / 255;
                int Bb = BackColor.B * alpha / 255 + frmColor.B * (255 - alpha) / 255;
                dragBckColor = Color.FromArgb(Rb, Gb, Bb);
            }
            else
            {
                dragBckColor = frmColor;
            }

            alpha = 255;
            bckColor = new SolidBrush(Color.FromArgb(alpha, dragBckColor));
        }
        else
        {
            bckColor = new SolidBrush(Color.FromArgb(alpha, this.BackColor));
        }

        if (this.BackColor != Color.Transparent | drag)
        {
            g.FillRectangle(bckColor, bounds);
        }

        bckColor.Dispose();
        g.Dispose();
        base.OnPaint(e);
    }

    protected override void OnBackColorChanged(EventArgs e)
    {
        if (this.Parent != null)
        {
            Parent.Invalidate(this.Bounds, true);
        }
        base.OnBackColorChanged(e);
    }

    protected override void OnParentBackColorChanged(EventArgs e)
    {
        this.Invalidate();
        base.OnParentBackColorChanged(e);
    }
}

Answer 2

You will need to use Opacity property and set it to zero to make form invisible.

If you want to make a control Transparent, as you have tried in your example, See this article

How to: Give Your Control a Transparent Background

It say the code you have written, must be in constructor of the control. Hence, I guess, you will need to create a custom control derived from your pnlSelectArea 's type most probaably a button. In in that custom control's constructor you can write code to set its style and color.

Answer 3

Here is what worked for me with because the other solutions did not work.

This is with transparent UserControl added to ListView/TreeView Control Collection

I know it says ButtonRenderer but it should work for any controls.

In the UserControl:

protected override void OnPaint(PaintEventArgs e)
{
    ButtonRenderer.DrawParentBackground(e.Graphics, this.ClientRectangle, this);
}

in the Parent control:

protected override void WndProc(ref Message m)
{
    if(m.Msg == 0xF)
        foreach(Control c in this.Controls) { c.Invalidate(); c.Update(); }

    base.WndProc(ref m);
}

Answer 4

great!! I finally managed to draw transparent shapes. I've added a virtual method

Draw(g);

right before

bckColor.Dispose();
g.Dispose();
base.OnPaint(e);

and at the end the declaration of the virtual method

protected virtual void Draw(Graphics g){ }

Now I can continue creating my own Transparent shapes, graphics etc ...

Answer 5

There is one simple workaround for this. You can create an image with a transparent background (PNG) and add it for the Image property of the icon. This works fine as information does not have much flexibility in styling. Sometime this might not be suitable for everyone. Remember this is only a workaround.

PS: Add where ever the text on the image and keep blank for the text property.
