Matplotlib: Why Does Setting Grid with Pyplot. Setp() Causes Error?
This Question Is Different from This Post, Which Is Discussing Other Ways to Set Grid Rather Than Using Pyplot. Setp(). Matplotlib. Pyplot. Setp() Could Be...
this question is different from this post, which is discussing other ways to set grid rather than using pyplot.setp().
matplotlib.pyplot.setp() could be used to set some properties for all subplots.
this piece of code
xlim = (-2,2)
ylim = (-2,2)
f, axs = plt.subplots(2, 2)
a = plt.setp(axs, xlim=xlim, ylim=ylim)
plt.show()
sets limits as (-2,2) for all subplots.
AxesSubplot.grid could be used to set grid lines
f, axs = plt.subplots(2, 2)
axs[0,0].grid(True)
plt.show()
I am trying to set grid lines by using pyplot.setp().
f, axs = plt.subplots(2, 2)
plt.setp(axs, grid=True)
plt.show()
get this error
--------------------------------------------------------------------------
AttributeError Traceback (most recent call last)
<ipython-input-10-5014b2a61ed3> in <module>()
1 f, axs = plt.subplots(2, 2)
----> 2 plt.setp(axs, grid=True)
3 plt.show()
~/anaconda3/envs/tf11/lib/python3.6/site-packages/matplotlib/pyplot.py in setp(obj, *args, **kwargs)
340 @docstring.copy(_setp)
341 def setp(obj, *args, **kwargs):
--> 342 return _setp(obj, *args, **kwargs)
343
344
~/anaconda3/envs/tf11/lib/python3.6/site-packages/matplotlib/artist.py in setp(obj, *args, **kwargs)
1505 # put args into ordereddict to maintain order
1506 funcvals = OrderedDict((k, v) for k, v in zip(args[::2], args[1::2]))
-> 1507 ret = [o.update(funcvals) for o in objs] + [o.set(**kwargs) for o in objs]
1508 return list(cbook.flatten(ret))
1509
~/anaconda3/envs/tf11/lib/python3.6/site-packages/matplotlib/artist.py in <listcomp>(.0)
1505 # put args into ordereddict to maintain order
1506 funcvals = OrderedDict((k, v) for k, v in zip(args[::2], args[1::2]))
-> 1507 ret = [o.update(funcvals) for o in objs] + [o.set(**kwargs) for o in objs]
1508 return list(cbook.flatten(ret))
1509
~/anaconda3/envs/tf11/lib/python3.6/site-packages/matplotlib/artist.py in set(self, **kwargs)
1013 key=lambda x: (self._prop_order.get(x[0], 0), x[0])))
1014
-> 1015 return self.update(props)
1016
1017 def findobj(self, match=None, include_self=True):
~/anaconda3/envs/tf11/lib/python3.6/site-packages/matplotlib/artist.py in update(self, props)
914
915 with cbook._setattr_cm(self, eventson=False):
--> 916 ret = [_update_property(self, k, v) for k, v in props.items()]
917
918 if len(ret):
~/anaconda3/envs/tf11/lib/python3.6/site-packages/matplotlib/artist.py in <listcomp>(.0)
914
915 with cbook._setattr_cm(self, eventson=False):
--> 916 ret = [_update_property(self, k, v) for k, v in props.items()]
917
918 if len(ret):
~/anaconda3/envs/tf11/lib/python3.6/site-packages/matplotlib/artist.py in _update_property(self, k, v)
910 func = getattr(self, 'set_' + k, None)
911 if not callable(func):
--> 912 raise AttributeError('Unknown property %s' % k)
913 return func(v)
914
AttributeError: Unknown property grid
I am asking for an explanation why this code causes error rather than a solution to set grid for all subplots.
2 Answers
No, you cannot use plt.setp to turn the grid on.
The reason is that the axes does not have an attribute grid and no set_grid method, but only a method .grid(..).
You would need to call that method,
for ax in axs.flat:
ax.grid(True)
Other options to turn the grid on are shown in How do I draw a grid onto a plot in Python?
It is possible using rcParams. You can use the following
import matplotlib.pyplot as plt
rc = {"axes.grid" : True}
plt.rcParams.update(rc)
xlim = (-2,2)
ylim = (-2,2)
f, axs = plt.subplots(2, 2)
a = plt.setp(axs, xlim=xlim, ylim=ylim)
plt.show()
