Modulo Function in C++, That Behaves Like Mod in Matlab
I Do a Simulation with a Lot of Particles (Up to 100000) in Periodic Domain(Box), and in Order Particles to Stay Inside the Box, I Use Modulo Function with...
I do a simulation with a lot of particles (up to 100000) in periodic domain(box), and in order particles to stay inside the box, I use modulo function with float or double numbers.
In Matlab everything works great with mod function. However in C++ I found out, that function fmod is not completely equal to Matlab's mod function:
mod(-0.5,10)=9.5 - I want this result in C++
fmod(-0.5,10)=-0.5 - I don't want this.
I, of course, can solve my problem with if statements. However, i think, it will affect efficiency (if statement in critical loop). Is there a way to implement this function without if statement? May be some other function?
Thanks.
5 Answers
Just use a conditional. It will not meaningfully affect efficiency.
inline double realmod (x, y)
{
result = fmod(x, y);
return result >= 0 ? result : result + y;
}
fmod() calls assembly instruction FPREM which takes 16-64 cycles (according to the Pentium manual, ). The jump instructions for the conditional and the floating point addition only amount to 5 or so.
When your code has floating point division, you don't need to sweat the small stuff.
Either use floor and regular division:
float modulo(float a, float q)
{
float b = a / q;
return (b - floor(b)) * q;
}
or you can add the divisor to the result of fmod without branching:
float modulo(float a, float q)
{
float m = fmod(a, q);
return m + q * (m < 0.f);
}
Based on Matlab mod(a, m) documentation and @QuestionC's answer -
A general solution that behaves exactly like Matlab - also for negative and zero divisor.
Tested against multiple values :
static inline double MatlabMod(double q, double m)
{
if(m == 0)
return q;
double result = fmod(q, m);
return ((result >= 0 && m > 0) || (q <= 0 && m < 0)) ? result : (result + m);
}
Tested with matlab for :
(q, m) -> result(54, 321) -> 54
(-50, 512) -> 462
(54, -152) -> -98
(-53, -500) -> -53
(-500, 300) -> 100
(-5000, 400) -> 200
(-1000, -360) -> -280
(500, 360) -> 140
(1000, 360) -> 280
(-1000, 360) -> 80
(-5051, 0) -> -5051
(512, 0) -> 512
(0, 52) -> 0
(0, -58) -> 0
Just add the divisor to the number you want to keep in the interval before you apply the modulo operator:
return fmod(a+q,q);
this requires no branching at all.
If you have to worry about a exeeding -q between two updates, you can make it more robust by e.g.:
return fmod(a+q*10,q);
which would work for a >= -10*q
The most straightforward with working for both floats and ints without any branching.
// b = MOD(a, m)
int a = a - m * floor(a / m) + m;
int b = a - m * floor(a / m);
