New Tsi Calls - Documentation for Bmc Ami Devx Code Pipeline 22.01

There are three new TSI calls available to use in custom Deploy code:

• DPLYPRTI, LIST – List Deploy Part Instance Log Entries
• DPLYPRTI, ADD – Add Deploy Part Instance Log Entry
• DPLYPRTI, CLEANUP – Clean Up Deploy Part Instance Log Entry

DPLYPRTI LIST

This call can be made at some point during the Promotion process (usually in the Set Post Exit) to list all the Target runtime members and libraries that have been deployed to by the Task being promoted. It details all the Deploy Part Instances that have been deployed for that Task from an Application Stream Level in the  Code Pipeline  lifecycle.

Table-DPLYPRTI LIST Input Fields describes the input and Table-DPLYPRTI LIST Output Fields describes the output fields.

DPLYPRTI LIST Input Fields

DPLYPRTI LIST Output Fields

DPLYPRTI ADD

This new  Code Pipeline call will add a Deploy Part Instance Log Entry. It is not required when the Deploy Implementation Type has been set to C (the Copy to the Target is performed internally by Code Pipeline ), because the Deploy Logging happens automatically. It is only required when the ITEM, GET call is being used to copy to the Target. In this situation, Deploy Logging must be requested manually using this new DPLYPRTI, ADD call.

The following table describes the input fields.

DPLYPRTI ADD Input Fields

DPLYPRTI CLEANUP

This new  Code Pipeline  call can be used when deleting members from the Target runtime libraries. It tracks this event by updating the current Deploy Part Instance Log Entry to become inactive.

The following table describes the input fields.

DPLYPRTI CLEANUP Input Fields

Sample Code

The code in the following figure shows an example Clean Up stub in the Set Post Exit. In the standard  Code Pipeline  delivered sample it could reside in WZUSETX.

Sample Code – Cleanup_Deploy

Cleanup_deploy:
/* ------------------------------------------------------------------ */
/* This function is called on a promote to cleanup the datasets       */
/* deployed at the previous level                                     */
/* ------------------------------------------------------------------ */

   call Open_Set
   "ISPEXEC TBSKIP ASTABLE"
   tbrc = rc
   Do While tbrc = 0
      DZTABLE = "DZTABLE"
      taskidx=c2x(taskid)
      STRMNAME = sxstrm
      LCLVL = oplvl
      retc = WZZTSI("DPLYPRTI","LIST")
      say "DPLYPRTI LIST rc = "retc
      Address ISPEXEC
      If retc = 0 then do
         "TBTOP" DZTABLE
         Do Until skiprc > 0
            "TBSKIP" DZTABLE
            skiprc = rc
            If rc = 0 then do
               say DPRTIID DPRTINAM STORTYPE STORNAME STORUSGE CTSRVRNM
               delpds = storname
               delmem = dprtinam
               Call Delete_Member
               retcu = WZZTSI("DPLYPRTI","CLEANUP")
               say "DPLYPRTI CLEANUP rc = "retcu
            End
         End
         "TBEND" DZTABLE
      End
   "ISPEXEC TBSKIP ASTABLE"
   tbrc = rc
   End
