Panic Bar Door Lock Mechanism

How it Works. Panic bars consist of a flat, horizontal bar attached to the inside of an outward-opening door. This flat bar retracts a latch mechanism when pushed, unlocking the door for fast exit. Doors using a classic crash bar require no knowledge or keys to operate and are ADA-compliant for handicapped usage.

Can panic hardware be locked?

No additional locking device (deadlock, chain, padlock and hasp, etc.) may be installed on a door required to have panic hardware, and panic hardware may not be equipped with any device that prevents the release of the latch when the touch-pad or cross-bar is pressed.

Is panic hardware required on exit doors?

Keep in mind that when an application requires panic hardware, all of the doors in the means of egress from that room or area will typically require panic hardware, including the exit access, the exit and the exit discharge.

How do you lock a push button door?

With most commercial lock functions that incorporate a turn-button, the button actually functions as both a push-button and a turn-button. The lock can be locked by simply pushing the turn-button; the building occupant does not have to turn the button to lock or unlock the door.

What is the second latch on a panic bar for?

This allows an authorized user to open the door from the exterior side of the opening. A second option for the exterior trim is the installation of a moveable handle or a handle with a keyed lock cylinder.

What is a panic lock?

A panic lock (also called a panic bar, a crash bar, or a panic device) is used to provide quick unlocking of a door in an emergency situation. A panic lock is designed to save lives.

What is panic hardware for doors?

An exit device – sometimes called a Panic Device or a Crash Bar – is mechanical door hardware operated from the inside of an outswing exit door through the use of a crossbar or push rail and extends at least halfway across its width.

What is a dogging mechanism?

In a nutshell, dogging a device holds the latchbolt retracted removing the need to turn the lever or push the panic bar to retract the latch and open the door. You essentially only have to push or pull the door for it to open when the exit hardware is “dogged”.

How do you unlock a panic door from the outside?

Locking the push bar door
Find the keyhole on the push bar. If the doorknob has a lock, look for a jagged slit on the door’s outward-facing knob.Make sure the key fits.Insert the key within the outer doorknob keyhole.Lock the door both from outside and inside.Check if the door is locked.

What is the difference between panic hardware and fire exit hardware?

Fire Exit Hardware is an exit device which is tested for both panic and fire conditions and is required to be used on fire doors where panic hardware is required by code or desired for durability. Since fire doors require positive-latching, fire exit hardware does not incorporate mechanical dogging.

What is a rim exit device?

Rim exit devices are a type of panic device that is used on out-swinging doors. This exit device hardware can have trim or levers on the other side of the door. They can be labeled as fire rated or just labeled as panic hardware. Rim exit devices can be used on single doors as well as double doors.

Where is NFPA panic hardware?

The required locations for panic hardware vary depending on which code has been adopted, but typically, panic hardware is required for assembly, educational/daycare, and high hazard occupancies, where the calculated occupant load is 50 people or more (International Building Code (IBC) and International Fire Code (IFC

Can you put a lock on a fire exit door?

Fire exit doors must not be locked with a key or padlock whilst a building is in use. However, when a building is unoccupied it can be locked as securely as required.

Can exit doors be locked?

in a means of egress must be maintained openable from the side from which egress is to be made without the use of a key. Such doors may be locked against opening from the opposite direction.
