Routing in Matdialog in Angular

I am trying to add routing to a Angular Material Mat Dialog in angular. But there is an problem occurring.

When I try to add the route URL manually from

to

or

it don't pop up

Tab Switching Problem

Also, There is another problem that when the dialog is opened for login and then if i tab switch to SignIn there is no change in URL

Navbar.component.ts ( Dialog Initializing Component )

import { Component, OnInit, Output, EventEmitter, Inject } from '@angular/core';
import { MAT_DIALOG_DATA, MatDialogRef } from '@angular/material/dialog';
import { MatDialog } from '@angular/material/dialog';
import { ActivatedRoute, Router } from '@angular/router';
import { takeUntil } from 'rxjs/operators';
import { Subject } from 'rxjs';

@Component({
  selector: 'app-navbar',
  templateUrl: './navbar.component.html',
  styleUrls: ['./navbar.component.css']
})
export class NavbarComponent implements OnInit {


  flag: boolean;
  currentDialog: MatDialogRef<any> = null;

  //Dialog init
  constructor(public dialog: MatDialog, private route: ActivatedRoute, private router: Router) {

   }

  openDialog(tabvalue: number) {

    console.log(tabvalue);
    this.currentDialog = this.dialog.open(DialogComponent, {
      data: {tabvalue},
    });

    this.currentDialog.afterClosed().subscribe(result => {
      console.log(`Dialog result: ${result}`);
      this.router.navigateByUrl('/');
    });
  }

  ngOnInit(): void {
  }

}

//  dialog.component.ts
@Component({
  selector: 'dialog-dialog',
  templateUrl: 'dialog.component.html',
})

export class DialogComponent {
  tabs = ['Login', 'Sign in'];

  constructor(@Inject(MAT_DIALOG_DATA) public data: any) { }

  // tabvalue have only two values 0 -> tabs[0] -> Login and 1 -> tabs[1] -> SignIn
  selected = this.data.tabvalue
}

Navbar.component.html ( template for above code )

<mat-toolbar mat-toolbar [routerLink]="['/']">

    <button mat-icon-button (click)="flag = !flag ; value()">

        <mat-icon>menu</mat-icon>
    </button>
    <a class="a-menu">
        <h1 class="h1-menu">Notes</h1>
    </a>
    <span class="example-spacer"></span>
    <button mat-raised-button routerLink="/login"  routerLinkActive="active" (click)="openDialog(0)">Login</button>
    &nbsp;
    <button mat-raised-button routerLink="/signin" routerLinkActive="active"  (click)="openDialog(1)">Sign In</button>
</mat-toolbar>

<!--app-navbar (valueChange)='sb.toggleCustom($event)'></app-navbar-->
<!--this is nothing-->

<app-sidebar [flag]="flag"></app-sidebar>

Dialog.component.html ( template for dialog )

<mat-dialog-content class="mat-typography">


    <mat-tab-group [selectedIndex]="selected">
        <mat-tab *ngFor="let tab of tabs; let index = index" [label]="tab">
            <app-login *ngIf="tab == 'Login'"></app-login>
            <app-signin *ngIf="tab == 'Sign in'"></app-signin>
        </mat-tab>

    </mat-tab-group>


</mat-dialog-content>
<mat-dialog-actions align="end">
    <button mat-button mat-dialog-close>Cancel</button>
    <button mat-button [mat-dialog-close]="true" cdkFocusInitial>{{selected == 0 ? 'Login' : 'Sign In'}}</button>
</mat-dialog-actions>

app.module.ts

import { BrowserModule } from '@angular/platform-browser';
import {BrowserAnimationsModule } from '@angular/platform-browser/animations'
import { NgModule } from '@angular/core';

import {A11yModule} from '@angular/cdk/a11y';
import {ClipboardModule} from '@angular/cdk/clipboard';
import {DragDropModule} from '@angular/cdk/drag-drop';
import {PortalModule} from '@angular/cdk/portal';
import {ScrollingModule} from '@angular/cdk/scrolling';
import {CdkStepperModule} from '@angular/cdk/stepper';
import {CdkTableModule} from '@angular/cdk/table';
import {CdkTreeModule} from '@angular/cdk/tree';
import {MatAutocompleteModule} from '@angular/material/autocomplete';
import {MatBadgeModule} from '@angular/material/badge';
import {MatBottomSheetModule} from '@angular/material/bottom-sheet';
import {MatButtonModule} from '@angular/material/button';
import {MatButtonToggleModule} from '@angular/material/button-toggle';
import {MatCardModule} from '@angular/material/card';
import {MatCheckboxModule} from '@angular/material/checkbox';
import {MatChipsModule} from '@angular/material/chips';
import {MatStepperModule} from '@angular/material/stepper';
import {MatDatepickerModule} from '@angular/material/datepicker';
import {MatDialogModule} from '@angular/material/dialog';
import {MatDividerModule} from '@angular/material/divider';
import {MatExpansionModule} from '@angular/material/expansion';
import {MatGridListModule} from '@angular/material/grid-list';
import {MatIconModule} from '@angular/material/icon';
import {MatInputModule} from '@angular/material/input';
import {MatListModule} from '@angular/material/list';
import {MatMenuModule} from '@angular/material/menu';
import {MatNativeDateModule, MatRippleModule} from '@angular/material/core';
import {MatPaginatorModule} from '@angular/material/paginator';
import {MatProgressBarModule} from '@angular/material/progress-bar';
import {MatProgressSpinnerModule} from '@angular/material/progress-spinner';
import {MatRadioModule} from '@angular/material/radio';
import {MatSelectModule} from '@angular/material/select';
import {MatSidenavModule} from '@angular/material/sidenav';
import {MatSliderModule} from '@angular/material/slider';
import {MatSlideToggleModule} from '@angular/material/slide-toggle';
import {MatSnackBarModule} from '@angular/material/snack-bar';
import {MatSortModule} from '@angular/material/sort';
import {MatTableModule} from '@angular/material/table';
import {MatTabsModule} from '@angular/material/tabs';
import {MatToolbarModule} from '@angular/material/toolbar';
import {MatTooltipModule} from '@angular/material/tooltip';
import { MatTreeModule } from '@angular/material/tree';
import { FormsModule, ReactiveFormsModule } from '@angular/forms';
import {MAT_FORM_FIELD_DEFAULT_OPTIONS} from '@angular/material/form-field';

import { Routes, RouterModule } from '@angular/router'; // CLI imports router
import { AppComponent } from './app.component';
import { NavbarComponent, DialogComponent } from './navbar/navbar.component';
import { SidebarComponent } from './sidebar/sidebar.component';
import { SigninComponent } from './signin/signin.component';
import { LoginComponent } from './login/login.component';
import { MainComponent } from './main/main.component';
import { PageNotFoundComponent } from './page-not-found/page-not-found.component';



const routes: Routes = [
  { path: '', component: NavbarComponent },
  { path: 'login', component: NavbarComponent },
  { path: 'signin', component: NavbarComponent },
  { path: '**', component: PageNotFoundComponent },
]; // sets up routes constant where you define your routes

@NgModule({
  declarations: [
    AppComponent,
    NavbarComponent,
    SidebarComponent,
    DialogComponent,
    SigninComponent,
    LoginComponent,
    MainComponent,
    PageNotFoundComponent
  ],
  imports: [
    BrowserModule,
    BrowserAnimationsModule,
    A11yModule,
    ClipboardModule,
    CdkStepperModule,
    CdkTableModule,
    CdkTreeModule,
    DragDropModule,
    MatAutocompleteModule,
    MatBadgeModule,
    MatBottomSheetModule,
    MatButtonModule,
    MatButtonToggleModule,
    MatCardModule,
    MatCheckboxModule,
    MatChipsModule,
    MatStepperModule,
    MatDatepickerModule,
    MatDialogModule,
    MatDividerModule,
    MatExpansionModule,
    MatGridListModule,
    MatIconModule,
    MatInputModule,
    MatListModule,
    MatMenuModule,
    MatNativeDateModule,
    MatPaginatorModule,
    MatProgressBarModule,
    MatProgressSpinnerModule,
    MatRadioModule,
    MatRippleModule,
    MatSelectModule,
    MatSidenavModule,
    MatSliderModule,
    MatSlideToggleModule,
    MatSnackBarModule,
    MatSortModule,
    MatTableModule,
    MatTabsModule,
    MatToolbarModule,
    MatTooltipModule,
    MatTreeModule,
    PortalModule,
    ScrollingModule,
    FormsModule,
    ReactiveFormsModule,
    RouterModule.forRoot(routes)


  ],
  exports: [RouterModule],
  providers: [
    { provide: MAT_FORM_FIELD_DEFAULT_OPTIONS, useValue: { appearance: 'fill' } },
  ],
  bootstrap: [AppComponent]
})
export class AppModule { }

Default View

On Click Login

Manually Typing URL

Output (without Dialog Box pop Up But URL changed)
