Scnbox Different Colour or Texture on Each Face

Question

I'm new to iOS development and I've got myself stumped. I am trying to render a cube using SceneKit that has a different colour for each face.

This is what I've got so far:

func sceneSetup() {
    // 1
    let scene = SCNScene()

    // 2
    let BoxGeometry = SCNBox(width: 0.9, height: 0.9, length: 0.9, chamferRadius: 0.0)

    BoxGeometry.firstMaterial?.diffuse.contents = UIColor.redColor()
    let cube = SCNNode(geometry: BoxGeometry)
    cube.position = SCNVector3(x: 0, y: 0, z: -1)
    scene.rootNode.addChildNode(cube)

    // 3
    sceneView.scene = scene
    sceneView.autoenablesDefaultLighting = true
    sceneView.allowsCameraControl = true

But I'd like each face to have a different colour. How do I do that?

Accepted Answer

The box is composed out of six different elements (one for each side). You may also have noticed that a geometry object has one property for the first material but also a property for an array of materials.

An object with multiple elements and multiple materials will pick the increment the material (and wrap) for each element.

For example 4 elements and 1 material

Element   1  2  3  4
Material  1  1  1  1

or 4 elements and 2 materials

Element   1  2  3  4
Material  1  2  1  2  // note that they are repeating

For example 4 elements and 7 materials

Element   1  2  3  4
Material  1  2  3  4  // (5, 6, 7) is unused

In the case of the box this means that you can use an array of six materials to have a unique material on each side of the box. I have an example of this in the sample code for one of the chapters for my Scene Kit book (in Objective-C):

// Each side of the box has its own color
// --------------------------------------
// All have the same diffuse and ambient colors to show the
// effect of the ambient light, even with these materials.

SCNMaterial *greenMaterial              = [SCNMaterial material];
greenMaterial.diffuse.contents          = [NSColor greenColor];
greenMaterial.locksAmbientWithDiffuse   = YES;

SCNMaterial *redMaterial                = [SCNMaterial material];
redMaterial.diffuse.contents            = [NSColor redColor];
redMaterial.locksAmbientWithDiffuse     = YES;

SCNMaterial *blueMaterial               = [SCNMaterial material];
blueMaterial.diffuse.contents           = [NSColor blueColor];
blueMaterial.locksAmbientWithDiffuse    = YES;

SCNMaterial *yellowMaterial             = [SCNMaterial material];
yellowMaterial.diffuse.contents         = [NSColor yellowColor];
yellowMaterial.locksAmbientWithDiffuse  = YES;

SCNMaterial *purpleMaterial             = [SCNMaterial material];
purpleMaterial.diffuse.contents         = [NSColor purpleColor];
purpleMaterial.locksAmbientWithDiffuse  = YES;

SCNMaterial *magentaMaterial            = [SCNMaterial material];
magentaMaterial.diffuse.contents        = [NSColor magentaColor];
magentaMaterial.locksAmbientWithDiffuse = YES;


box.materials =  @[greenMaterial,  redMaterial,    blueMaterial,
                   yellowMaterial, purpleMaterial, magentaMaterial];

Answer 2

Here's a Swift 4 answer.

    let colors = [UIColor.green, // front
                  UIColor.red, // right
                  UIColor.blue, // back
                  UIColor.yellow, // left
                  UIColor.purple, // top
                  UIColor.gray] // bottom

    let sideMaterials = colors.map { color -> SCNMaterial in
        let material = SCNMaterial()
        material.diffuse.contents = color
        material.locksAmbientWithDiffuse = true
        return material
    }

    materials = sideMaterials

To change the front material just grab the material and change it's content

let frontMaterial = materials[0]
frontMaterial.diffuse.contents = UIColor.white

Answer 3

thai you for the fast help. i used the code you posed but was unable to use NSColor so i tried uicolor but all i was getting was a black cube so i tried this and i got it working

    let BoxGeometry = SCNBox(width: 0.95, height: 0.95, length: 0.95, chamferRadius: 0.0)

    let greenMaterial = SCNMaterial()
    greenMaterial.diffuse.contents = UIImage(named: "g")
    greenMaterial.locksAmbientWithDiffuse = true;

    let redMaterial = SCNMaterial()
    redMaterial.diffuse.contents = UIImage(named: "r")
    redMaterial.locksAmbientWithDiffuse = true;


    let blueMaterial  = SCNMaterial()
    blueMaterial.diffuse.contents = UIImage(named: "b")
    blueMaterial.locksAmbientWithDiffuse = true;


    let yellowMaterial = SCNMaterial()
    yellowMaterial.diffuse.contents = UIImage(named: "y")
    yellowMaterial.locksAmbientWithDiffuse = true;


    let purpleMaterial = SCNMaterial()
    purpleMaterial.diffuse.contents = UIImage(named: "p")
    purpleMaterial.locksAmbientWithDiffuse = true;


    let WhiteMaterial = SCNMaterial()
    WhiteMaterial.diffuse.contents = UIImage(named: "w")
    WhiteMaterial.locksAmbientWithDiffuse   = true;


    BoxGeometry.materials =  [greenMaterial,  redMaterial,    blueMaterial,
    yellowMaterial, purpleMaterial, WhiteMaterial];

g is a jpeg of a green and so on and that has got it working now.
