Set Lan to Take Network Priority Before Wi-Fi on Windows 7
So Far I've Tried to Prioritize Lan the Following: Moving the "Local Area Connection" up in the Advanced Settings as Shown in How to Change the Network...
So far I've tried to prioritize LAN the following:
- Moving the "Local Area Connection" up in the advanced settings as shown in How to change the network connection priority in Windows 7
- and deactivating the automatic metric and assigning the values 1 to lan and 2 to the wifi adapter as seen at the end of How to change the binding order of network adapters in Windows XP and in Windows 2000.
Sadly that didn't change anything. I have to deactivate my wireless adapter to get Windows to use the LAN connection. Any ideas?
I am running Windows 7 Ultimate on a Lenovo G580 with a Broadcom 802.11n network adapter and a "Atheros AR8162/8166/8168 PCI-E Fast Ethernet Controller (NDIS 6.20)".
My router supports 54 MBit/s which should be beaten by the 10/100 Base-T standard ethernet, right?
IPv4 Route Table
===========================================================================
Active Routes:
Network Destination Netmask Gateway Interface Metric
0.0.0.0 0.0.0.0 192.168.178.1 192.168.178.57 2
0.0.0.0 0.0.0.0 192.168.178.1 192.168.178.46 4
127.0.0.0 255.0.0.0 Auf Verbindung (German: on-link) 127.0.0.1 306
127.0.0.1 255.255.255.255 Auf Verbindung 127.0.0.1 306
127.255.255.255 255.255.255.255 Auf Verbindung 127.0.0.1 306
192.168.178.0 255.255.255.0 Auf Verbindung 192.168.178.57 257
192.168.178.0 255.255.255.0 Auf Verbindung 192.168.178.46 258
192.168.178.46 255.255.255.255 Auf Verbindung 192.168.178.46 258
192.168.178.57 255.255.255.255 Auf Verbindung 192.168.178.57 257
192.168.178.255 255.255.255.255 Auf Verbindung 192.168.178.57 257
192.168.178.255 255.255.255.255 Auf Verbindung 192.168.178.46 258
224.0.0.0 240.0.0.0 Auf Verbindung 127.0.0.1 306
224.0.0.0 240.0.0.0 Auf Verbindung 192.168.178.57 257
224.0.0.0 240.0.0.0 Auf Verbindung 192.168.178.46 258
255.255.255.255 255.255.255.255 Auf Verbindung 127.0.0.1 306
255.255.255.255 255.255.255.255 Auf Verbindung 192.168.178.57 257
255.255.255.255 255.255.255.255 Auf Verbindung 192.168.178.46 258
===========================================================================
Persistent Routes:
None
and heres the same with 100 wlan metric:
IPv4 Route Table
===========================================================================
Active Routes:
Network Destination Netmask Gateway Interface Metric
0.0.0.0 0.0.0.0 192.168.178.1 192.168.178.57 2
0.0.0.0 0.0.0.0 192.168.178.1 192.168.178.46 102
127.0.0.0 255.0.0.0 On-link 127.0.0.1 306
127.0.0.1 255.255.255.255 On-link 127.0.0.1 306
127.255.255.255 255.255.255.255 On-link 127.0.0.1 306
192.168.178.0 255.255.255.0 On-link 192.168.178.57 257
192.168.178.0 255.255.255.0 On-link 192.168.178.46 356
192.168.178.46 255.255.255.255 On-link 192.168.178.46 356
192.168.178.57 255.255.255.255 On-link 192.168.178.57 257
192.168.178.255 255.255.255.255 On-link 192.168.178.57 257
192.168.178.255 255.255.255.255 On-link 192.168.178.46 356
224.0.0.0 240.0.0.0 On-link 127.0.0.1 306
224.0.0.0 240.0.0.0 On-link 192.168.178.57 257
224.0.0.0 240.0.0.0 On-link 192.168.178.46 356
255.255.255.255 255.255.255.255 On-link 127.0.0.1 306
255.255.255.255 255.255.255.255 On-link 192.168.178.57 257
255.255.255.255 255.255.255.255 On-link 192.168.178.46 356
===========================================================================
Persistent Routes:
None
Any idea why the one and two become metric two and four and one and 100 become two and 102?
Both wired and wireless adapters connected are connected to the same subnet. The only thing that runs on startup is my anti-virus program. At least from what I can control in msconfig.
3 Answers
To make the wired LAN connection take priority you need to change the metric for the WIFI connection in the advanced settings pane of the WIFI connections' properties.
Untick the 'Automatic metric' and set the metric to 9999 manually
Next open a commandline with admin rights and submit this command to clear the routing tables:
route /f
After this step reboot windows to make sure the new metric value gets used.
Upon rebooting the routing tables will be rebuilt using ARP-discovery, causing the new metrics to be assigned to the routes. The net effect will be that to your TCP/IP stack it will look as if hosts/devices connected to the wired LAN have a more efficient route than those connecting via WIFI only.
The automatic metrics are based on connection speed, so while a 100Mbps LAN connection beats a 54Mbps 802.11g network, a 150 or 300Mbps 802.11n network will win.
The adapter binding order in your first bullet is unlikely to be useful here. The interface metrics in your second bullet should have done the trick... Perhaps a more extreme value is needed (say 1 for LAN, 100 for WLAN).
Can you provide the "IPv4 Route Table" section of a netstat -rn command? Those are the final metrics as the TCP/IP stack actually evaluates them and should be the source of truth.
