Share Samba Drive with Windows Without Having to Allow Guest Access
I Am Trying to Set up a Simple Samba Share Between My Raspberry Pi and My Windows 10. This Is My Config: [Global] Min Protocol = Smb2 Workgroup = Workgroup...
I am trying to set up a simple samba share between my raspberry pi and my windows 10. This is my config:
[global]
min protocol = SMB2
workgroup = WORKGROUP
wins support = no
dns proxy = no
guest account = nobody
interfaces = 127.0.0.1, 192.168.2.0/24
bind interfaces only = yes
hosts allow = 127.0.0.1 192.168.2.0/24
hosts deny = 0.0.0.0/0
log file = /var/log/samba/log.%m
log level = 1
max log size = 1000
panic action = /usr/share/samba/panic-action %d
security = user
server role = standalone server
passdb backend = tdbsam
obey pam restrictions = yes
unix password sync = yes
passwd program = /usr/bin/passwd %u
passwd chat = *Enter\snew\s*\spassword:* %n\n *Retype\snew\s*\spassword:* %n\n *password\supdated\ssuccessfully* .
pam password change = yes
encrypt passwords = yes
map to guest = never
usershare allow guests = no
auto services = pi
#======================= Share Definitions =======================
[homes]
comment = Home Directories
browseable = no
read only = yes
create mask = 0700
directory mask = 0700
valid users = %S
[printers]
comment = All Printers
browseable = no
path = /var/spool/samba
printable = yes
guest ok = no
read only = yes
create mask = 0700
[print$]
comment = Printer Drivers
path = /var/lib/samba/printers
browseable = yes
read only = yes
guest ok = no
[pi]
comment = pi samba share
path = /home/shares/pi
browseable = yes
writeable = true
admin users = pi
public = no
valid users = pi
hide dot files = no
In order for this to work, I had to follow this article Guest access in SMB2 to change the registry keys for allowing guest access.
What would I need to change in my config so that I don't have change any registry keys for everything to work (meaning: I can successfully access /home/shares/pi from my Windows 10)?
I have various settings in my config that, to my understanding, prohibit guest access, so I don't understand why I still had to enable it.
1 Answer
You have two possible approaches:
- You can access the files as guest.
- You can configure accounts that have to authenticate.
A guest account is fine if all the users should have access anyway, but it's not what you desire, so you must configure one ore more accounts. Samba allows different kinds of accounts, they are configured with the passdb backend option:
smbpasswd - The old plaintext passdb backend. Some Samba features will not work if this passdb backend is used. Takes a path to the smbpasswd file as an optional argument.
tdbsam - The TDB based password storage backend. Takes a path to the TDB as an optional argument (defaults to passdb.tdb in the private dir directory.
ldapsam - The LDAP based passdb backend. Takes an LDAP URL as an optional argument (defaults to ldap://localhost)
The smbpasswd is the oldest and most simple, it's just a plain file similar to /etc/passwd. The tdbsam uses a binary tdb file and can store more information about user accounts. LDAP is more interesting if you want to manage many accounts and/or already have an LDAP server.
See also smbpasswd for adding accounts and changing password.
