FIELD
DESCRIPTION
Driving Object
Displays the name of the driving object from which you want to extract related data.
Extract Navigation Criteria
Navigation criteria determines the extend of how File-AID/RDX chases the related objects from the driving object. On this panel, you specify the Navigation Criteria globally, for all included objects and relationships. In the Detail View panels you may then determine the navigation on an individual object or relationship level.
Important
When your profile has navigation criteria Direct set to C or P, all Extract Navigation Criteria fields are protected and cannot be modified during the extract specification. The Description of the Direct field will then also display the respective status, either ** Children only or ** Direct Plus.
Direct
Specify to extract the dependents of the driving object (starting point) and their dependents.
Y
Extract the dependents of the driving object and their dependents.
N
Do NOT extract the dependents of the driving object and their dependents.
C
(All Children only) Extract the dependents of the driving object and all of their dependents only. This option ignores all other Navigational Criteria Options (DPSI) settings and cannot be modified during the extract specification.
Using the C method to extract data and only its dependent data can lead to extracted data that is not loadable because of referential integrity issues due to the omitted related parent data. This can be useful for extracting specific data that is then used for a purge procedure.
P
(Plus) Extract all of the direct relationships of the driving object, i.e. all of its parents and first level dependents only. Direct "Plus" means resolve all objects’ parents until there are no more parents to return. This option ignores all other Navigational Criteria Options (DPSI) setting sand cannot be modified during the extract specification.
Important
The C and P settings for Direct can only be set in the profile. The profile settings are used to build the relationship tree with its related objects when starting an extract specification.
Parents
Extract the parents of all extracted data to maintain the integrity of the extracted data.
Siblings
Extract other dependents of the extracted parents from the same relationships.
Indirect
Extract other dependents of the extracted parents from other relationships.
Extract Scope Detail View
Specify whether you want to view the list of relationships or list of related objects. Set to R or O to view the related objects and their relationships in more detail. In the detail panels, you may apply extract and navigation controls to individual relationships or objects.
N (None)
None does not display either of the detail extract scope panels.
O (Object)
Object displays the Extract Scope - Object View panel, listing all objects related to the driving object from which to extract data. For more information, see Extract Scope - Object View.
R (Relationship)
Relationship displays the Extract Scope - Relationship View panel, listing all the relationships associated with the driving object from which to extract data. For more information, see Relationship Navigation Criteria.
Extract Options
Use these fields to limit the number records to be extracted in this request.
Cycle Count
Specify the maximum number of cycles for all relationships leading from the object. Cycle count limits the number of times an object can be visited during an extract. This global setting for the Cycle Count can be overridden for each individual relationship (see Cycle).
Maximum Total Rows/Records From All Objects
Specify the maximum number of rows or records you want to extract from all related objects. Enter an asterisk (*) to set no limit.
Action When Maximum Count Is Reached
Specify how the extract should terminate when the maximum count has been reached:
Q
Quiesce resolves all orphan records after maximum count has been reached. (May result in more records than the maximum count.)
S
Stop does not resolve possible orphan records (may extract dependent records without their parents).
Extract from DB2 using Uncommitted Reads
Specify whether File-AID/RDX should extract data from Db2 objects that include Uncommitted Reads or not.
The field is prefilled with the specified UNCOMMITTED_READ_DEFAULT configuration parameter value (Yes or No) of the Db2 Environment PARMLIB member or with the current profile value (Yes or No) if UNCOMMITTED_READ_DEFAULT is set to blank (default, see also UNCOMMITTED_READ_DEFAULT in the File-AID Advanced Configuration Guide).
Extract IMPLICITLY HIDDEN columns
Specify whether File-AID/RDX should extract data from Db2 columns that are defined as IMPLICITLY HIDDEN. When this option is set to Y, the resulting File-AID/RDX extract file will include the data from IMPLICITLY HIDDEN columns.
Extract from image copy
Specify whether File-AID/RDX should extract data from Db2 Image Copy data sets or not. This option is only available if your site installation set the parameter variable UIMGCPY to Yes. For more information, see ALLOW_EXTRACT_FROM_DB2_IMAGE_COPY in File-AID Advanced Configuration Guide .
Y
File-AID/RDX extracts related data from the most recent, full Db2 Image Copy for the applicable tablespaces.
For partitioned tablespaces, File-AID/RDX extracts related data from image copy data sets as follows:
- If the most recent image copy is for the entire tablespace, File-AID/RDX uses entire the data set name.
- If the most recent image copy is for a partitioned tablespace, File-AID/RDX collects the data set names from the catalog for all other partitions and uses those names.
An image copy data set must exist in the MVS catalog for each Db2 table in the extract request. If not, the extract terminates.
To extract data from a Db2 Image Copy, you must have one of the following authorization privileges:
- RECOVERDB privilege for the database
- DBADM, or DBCTRL authority for the database
- SYSCTRL or SYSADM authority
N
File-AID/RDX will extract from the regular Db2 tables.
Important
The Extract from image copy option requires that File-AID/RDX be executed from an authorized library. Furthermore, the Extract from image copy option is not available:
- for Db2 views.
- for interactive execution (see also MODE ).
- when extracting from a remote location.
SELECT FROM Temporal Table
Enter Yes if you want to specify or modify a time-period and date/timestamps for Temporal Tables or Temporal Views. File-AID/RDX will display the “SELECT FROM Temporal Table” screen when you press Enter. Starting with Db2 Version 11, temporal support allows period specifications and period clauses to be specified for views. The same rules apply for views as do for tables.
Enter No (default) if you don’t want to display the “SELECT FROM Temporal Table” screen.
The status *Defined * displays if a SELECT FROM Temporal Table statement has already been defined, otherwise *None* displays.
If you want to extract data from temporal tables or views without a SELECT FROM Temporal Table statement, make sure *None* displays. To change the status from *Defined * to *None*, enter Yes in the SELECT FROM Temporal Table field, then set the Use System Time and Use Business Time to No in the “SELECT FROM Temporal Table” screen.
Important
When the *Defined * status displays and the extract request includes one or more temporal tables or views, File-AID/RDX will include the SELECT FROM Temporal Table statement even if the SELECT FROM Temporal Table field is set to N.
The SELECT FROM Temporal Table statement is only generated for each Temporal Table or Temporal View in the extract request.Whenever the selection is based on SYSTEM_TIME, it is possible that some rows come from the base table and some from the history table.
The *Defined * status is saved for this extract.
The SELECT FROM Temporal Table field will be reset to its default (No, *None*) when you exit the extract - DB2 Driving Object screen.
Scope Summary Counts
The following fields display how many objects and relationships will be included in the extract based on the specified Navigational Criteria specified.
Relationships Active
Displays how many relationships will be used to extract data from the related objects.
Related DB2 objects
Displays how many related Db2 objects will be accessed to extract data from.
Related MVS objects
Displays how many related MVS objects will be accessed to extract data from.
Output Key files
Displays for how many Output Key files File-AID/RDX will create for this extract request.
