I'd Like to Have a Div That Looks Like This: Is This Possible to Do with Html + Css? I Will Also Be Animating This Div with jQuery. When the Div Is Hidden I...
I'd like to have a div that looks like this:
Is this possible to do with HTML + CSS? I will also be animating this div with jQuery. When the div is hidden I would like the title and the top line to show.
9 Answers
Yes, but it's not a div, it's a fieldset
fieldset {
border: 1px solid #000;
}<fieldset>
<legend>AAA</legend>
</fieldset>You can do something like this, where you set a negative margin on the h1 (or whatever header you are using)
div{
height:100px;
width:100px;
border:2px solid black;
}
h1{
width:30px;
margin-top:-10px;
margin-left:5px;
background:white;
}
Note: you need to set a background as well as a width on the h1
Example:
EDIT
To make it work with hiding the div, you could use some jQuery like this
$('a').click(function(){
var a = $('h1').detach();
$('div').hide();
$(a).prependTo('body');
});
(You will need to modify...)
Example #2:
I know a bit late to the party, however I feel the answers could do with some more investigation/input. I have managed to create the situation without using the fieldset tag - that is wrong anyway as if I'm not in a form then that isn't really what I should be doing.
/* Styles go here */
#info-block section {
border: 2px solid black;
}
.file-marker > div {
padding: 0 3px;
height: 100px;
margin-top: -0.8em;
}
.box-title {
background: white none repeat scroll 0 0;
display: inline-block;
padding: 0 2px;
margin-left: 8em;
}<aside id="info-block">
<section class="file-marker">
<div>
<div class="box-title">
Audit Trail
</div>
<div class="box-contents">
<div id="audit-trail">
</div>
</div>
</div>
</section>
</aside>This can be viewed in this plunk:
What this achieves is the following:
no use of fieldsets.
minimal use if CSS to create effect with just some paddings.
Use of "em" margin top to create font relative title.
use of display inline-block to achieve natural width around the text.
Anyway I hope that helps future stylers, you never know.
Text in Border with transparent text background
.box{
background-image: url("");
width: 350px;
padding: 10px;
}
/*begin first box*/
.first{
width: 300px;
height: 100px;
margin: 10px;
border-width: 0 2px 0 2px;
border-color: #333;
border-style: solid;
position: relative;
}
.first span {
position: absolute;
display: flex;
right: 0;
left: 0;
align-items: center;
}
.first .foo{
top: -8px;
}
.first .bar{
bottom: -8.5px;
}
.first span:before{
margin-right: 15px;
}
.first span:after {
margin-left: 15px;
}
.first span:before , .first span:after {
content: ' ';
height: 2px;
background: #333;
display: block;
width: 50%;
}
/*begin second box*/
.second{
width: 300px;
height: 100px;
margin: 10px;
border-width: 2px 0 2px 0;
border-color: #333;
border-style: solid;
position: relative;
}
.second span {
position: absolute;
top: 0;
bottom: 0;
display: flex;
flex-direction: column;
align-items: center;
}
.second .foo{
left: -15px;
}
.second .bar{
right: -15.5px;
}
.second span:before{
margin-bottom: 15px;
}
.second span:after {
margin-top: 15px;
}
.second span:before , .second span:after {
content: ' ';
width: 2px;
background: #333;
display: block;
height: 50%;
}<div class="box">
<div class="first">
<span class="foo">FOO</span>
<span class="bar">BAR</span>
</div>
<br>
<div class="second">
<span class="foo">FOO</span>
<span class="bar">BAR</span>
</div>
</div><fieldset>
<legend> YOUR TITLE </legend>
<p>
Lorem ipsum dolor sit amet, est et illum reformidans, at lorem propriae mei. Qui legere commodo mediocritatem no. Diam consetetur.
</p>
</fieldset>You can use a fieldset tag.
<!DOCTYPE html>
<html>
<body>
<form>
<fieldset>
<legend>Personalia:</legend>
Name: <input type="text"><br>
Email: <input type="text"><br>
Date of birth: <input type="text">
</fieldset>
</form>
</body>
</html>Check this link: HTML Tag
For a duplicate, here another option with transform, no fieldset ( and rounded border required in the duplicates) :
position or transform can help you too :
* { margin: 0; padding:0; box-sizing:border-box; } .fieldset { border: solid; color: #353fff; border-radius: 1em; margin: 2em 1em 1em; padding:0 1em 1em; } .legend { transform: translatey(-50%); width: max-content; background: white; padding: 0 0.15em; } .fieldset li { list-style-type: " - "; }<div class="fieldset"> <h1 class="legend">Some Title</h1> <ul> <li>Item</li> <li>Item</li> <li>Item</li> <li>Item</li> </ul> </div>
If you are not in a position to add a field set, you can add a background to the element. In my situation, I had different colors in the input element and outside the input element, and also we have a hover color for the input element. So this is a fix I added linear-gradient background with outside color in the top half and transparent color in the bottom half. I added the transparent color to the bottom half inorder to see the hover color when hovered.
.class-name {
background: linear-gradient(to bottom, #2a2b2d 50%, transparent 50%);
}
It is possible by using the legend tag. Refer to
