Trouble Setting up Openvpn

Hey I've been trying to connect to the OpenVPN I've set up on my router via Ubuntu but it keeps timing out. I tested it on a Windows device and it connects with no problems, so I know it has to be something I'm overlooking in Network Manager. I checked my routers system logs and the error displayed is:

Jan  1 16:18:01 openvpn[6203]: TCP connection established with [AF_INET]192.168.1.139:43908

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 TLS: Initial packet from [AF_INET]192.168.1.139:43908, sid=362f6bd8 58b312d1

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 PLUGIN_CALL: POST /usr/lib/ status=0

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 TLS: Username/Password authentication succeeded for username 'masterofnone' [CN SET]

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 WARNING: 'dev-type' is used inconsistently, local='dev-type tap', remote='dev-type tun'

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 WARNING: 'link-mtu' is used inconsistently, local='link-mtu 1592', remote='link-mtu 1540'

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 WARNING: 'tun-mtu' is used inconsistently, local='tun-mtu 1532', remote='tun-mtu 1500'

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 WARNING: 'auth' is used inconsistently, local='auth SHA1', remote='auth [null-digest]'

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 Data Channel Encrypt: Cipher 'AES-128-CBC' initialized with 128 bit key

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 Data Channel Encrypt: Using 160 bit message hash 'SHA1' for HMAC authentication

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 Data Channel Decrypt: Cipher 'AES-128-CBC' initialized with 128 bit key

Jan  1 16:18:02 openvpn[6203]: 192.168.1.139:43908 Data Channel Decrypt: Using 160 bit message hash 'SHA1' for HMAC authentication

Jan  1 16:18:03 openvpn[6203]: 192.168.1.139:43908 Control Channel: TLSv1, cipher TLSv1/SSLv3 DHE-RSA-AES256-SHA

Jan  1 16:18:03 openvpn[6203]: 192.168.1.139:43908 [masterofnone] Peer Connection Initiated with [AF_INET]192.168.1.139:43908

Jan  1 16:18:03 openvpn[6203]: masterofnone/192.168.1.139:43908 MULTI: no dynamic or static remote --ifconfig address is available for
masterofnone/192.168.1.139:43908

Jan  1 16:18:03 openvpn[6203]: masterofnone/192.168.1.139:43908 Connection reset, restarting [0]

Jan  1 16:18:03 openvpn[6203]: masterofnone/192.168.1.139:43908 SIGUSR1[soft,connection-reset] received, client-instance restarting

Any help would be greatly appreciated. Thanks
