True Random Number Generator Using Vhdl

There is NO such thing as a "true" random number generator. This is one of my favorite pseudo-random generators however, and would be fun to implement in VHDL.

Also, see this:

The only thing that I can think of to get you "better" randomness would be to do something like write a file and then read a file. The scheduler on the host PC might have enough entropy associated with it to cause some variance in the time it takes for these operations and you could use that time as a key to seed your algorithm.

Since you are asking about VHDL, you want to design special-purpose hardware. Now if you operate hardware in a way which should never be done for digital logic, you might get some kind of "true" random behavior.
If, e.g., you design a circuit with a D-type flip-flop that is clocked when its data input changes its level, the output becomes metastable, i.e. is some time undefined (between 0 and 1), before it becomes stable as 0 or 1 again. How long this takes, depends among others on the electric noise, e.g. is random. I could imagine that you can use such effects to make a random generator.

thank u all for ur replies.I'm thinking to use a register holding different values and take it each time the repetition starts. the idea is to provide different seed values so I can get random values. Since I'm new to VHDL coding, Im not sure if this works but just a try from my side if I can do like this. Any suggestions are welcomed on this.

Contrary to the claims of most of the other answers, there are several TRNG designs for FPGAs mostly based on ring oscillators or self-timed rings, see e.g.

B. Yang, "True Random Number Generators for FPGAs," PhD thesis, KU Leuven, N. Mentens, and I. Verbauwhede (promotors), 2018.

and

VHDL TRNG designs

You're not going to get a true random number generator out of an FPGA / VHDL. The best you can hope for is a h/w PRNG that's readable from some register somewhere.

You might choose to implement one of the PRNG algorithms out there. You're then going to have to trust the algorithm designer and then trust which ever VHDL implementation you go with (your own or one you acquire off someone else). You might start by looking at:
