Use Images Like Checkboxes

Question

I would like to have an alternative to a standard checkbox - basically I'd like to use images and when the user clicks the image, fade it out and overlay a tick box.

In essence, I want to do something like Recaptcha 2 does when it gets you to click images that meet a certain criteria. You can see a Recaptcha demo here but it might sometimes get you to solve text questions, as opposed to the image selection. So here's a screenshot:

When you click one of the images (in this case, containing a picture of steak), the image you click shrinks in size and the blue tick appears, indicating that you've ticked it.

Let's say I want to reproduce this exact example.

I realise I can have 9 hidden checkboxes, and attach some jQuery so that when I click the image, it selects/deselects the hidden checkbox. But what about the shrinking of the image/overlaying the tick?

Accepted Answer

Pure semantic HTML/CSS solution

This is easy to implement on your own, no pre-made solution necessary. Also it will teach you a lot as you don't seem too easy with CSS.

Must Read

This is what you need to do:

Your checkboxes need to have distinct id attributes. This allows you to connect a <label> to it, using the label's for-attribute.

Example:

<input type="checkbox" id="myCheckbox1" />
<label for="myCheckbox1"><img src="" /></label>

Attaching the label to the checkbox will trigger a browser behaviour: Whenever someone clicks the label (or the image inside it), the checkbox will be toggled.

Next, you hide the checkbox by applying for example display: none; to it.

Now all that is left to do is set the style you want for your label::before pseudo element (which will be used as the visual checkbox replacement elements):

label::before {
    background-image: url(../path/to/unchecked.png);
}

In a last tricky step, you make use of CSS' :checked pseudo selector to change the image when the checkbox is checked:

:checked + label::before {
    background-image: url(../path/to/checked.png);
}

The + (adjacent sibling selector) makes sure you only change labels that directly follow the hidden checkbox in the markup.

You can optimize that by putting both images in a spritemap and only applying a change in background-position instead of swapping the image.

Of course you need to position the label correctly and apply display: block; and set correct width and height.
