Use of Cudamalloc(). Why the Double Pointer?

Question

I am currently going through the tutorial examples on to learn CUDA. The code which demostrates __global__ functions is given below. It simply creates two arrays, one on the CPU and one on the GPU, populates the GPU array with the number 7 and copies the GPU array data into the CPU array.

#include <stdlib.h>
#include <stdio.h>

__global__ void kernel(int *array)
{
  int index = blockIdx.x * blockDim.x + threadIdx.x;

  array[index] = 7;
}

int main(void)
{
  int num_elements = 256;

  int num_bytes = num_elements * sizeof(int);

  // pointers to host & device arrays
  int *device_array = 0;
  int *host_array = 0;

  // malloc a host array
  host_array = (int*)malloc(num_bytes);

  // cudaMalloc a device array
  cudaMalloc((void**)&device_array, num_bytes);

  int block_size = 128;
  int grid_size = num_elements / block_size;

  kernel<<<grid_size,block_size>>>(device_array);

  // download and inspect the result on the host:
  cudaMemcpy(host_array, device_array, num_bytes, cudaMemcpyDeviceToHost);

  // print out the result element by element
  for(int i=0; i < num_elements; ++i)
  {
    printf("%d ", host_array[i]);
  }

  // deallocate memory
  free(host_array);
  cudaFree(device_array);
}

My question is why have they worded the cudaMalloc((void**)&device_array, num_bytes); statement with a double pointer? Even here definition of cudamalloc() on says the first argument is a double pointer.

Why not simply return a pointer to the beginning of the allocated memory on the GPU, just like the malloc function does on the CPU?

Accepted Answer

All CUDA API functions return an error code (or cudaSuccess if no error occured). All other parameters are passed by reference. However, in plain C you cannot have references, that's why you have to pass an address of the variable that you want the return information to be stored. Since you are returning a pointer, you need to pass a double-pointer.

Another well-known function which operates on addresses for the same reason is the scanf function. How many times have you forgotten to write this & before the variable that you want to store the value to? ;)

int i;
scanf("%d",&i);

Answer 2

This is simply a horrible, horrible API design. The problem with passing double-pointers for an allocation function that obtains abstract (void *) memory is that you have to make a temporary variable of type void * to hold the result, then assign it into the real pointer of the correct type you want to use. Casting, as in (void**)&device_array, is invalid C and results in undefined behavior. You should simply write a wrapper function that behaves like normal malloc and returns a pointer, as in:

void *fixed_cudaMalloc(size_t len)
{
    void *p;
    if (cudaMalloc(&p, len) == success_code) return p;
    return 0;
}

Answer 3

In C/C++, you can allocate a block of memory dynamically at runtime by calling the malloc function.

int * h_array;
h_array = malloc(sizeof(int));

The malloc function returns the address of the allocated memory block which can be stored in a variable of some kind of pointer.
Memory allocation in CUDA is a bit different in two ways,

The cudamalloc return an integer as error code instead of a pointer to the memory block.
In addition to the byte size to be allocated, cudamalloc also requires a double void pointer as its first parameter.

int * d_array cudamalloc((void **) &d_array, sizeof(int))

The reason behind the first difference is that all CUDA API function follows the convention of returning an integer error code. So to make things consistent, cudamalloc API also returns an integer.

There requirements for a double pointer as the function first argument can be understood in two steps.

Firstly, since we have already decided to make the cudamalloc return an integer value, we can no longer use it to return the address of the allocated memory. In C, the only other way for a function to communicate is by passing the pointer or address to the function. The function can make changes to the value stored at the address or the address where the pointer is pointing. The changes to those value can be later retrieved outside the function scope by using the same memory address.

Must Read

how the double pointer works

The following diagram illustrated how it works with the double pointer.

int cudamalloc((void **) &d_array, int type_size) {
  *d_array = malloc(type_size);
  return return_code;
}
