Validating Helm Chart Content

You can lint the chart by going helm lint ./mychart which should print the following if an issue is found:

$ helm lint ./mychart
==> Linting ./mychart
[ERROR] Chart.yaml: version is required
[INFO] Chart.yaml: icon is recommended

Error: 1 chart(s) linted, 1 chart(s) failed

See helm lint.

Use kubeconform.

helm template ./mychart | kubeconform -strict

If you have CRDs you may need to use kubeconform -ignore-missing-schemas. I would recommend supplying the schema version: kubeconform -kubernetes-version 1.18.

A recommendation: specialise your charts and validate them. Examples follow.

Simple:

helm template --set some.key="val" | kubeconform -strict

Complex:

VALUES_FILE=$(cat << EOF
some:
  key: "val"

another:
  key:
    another: "val"
EOF
)
# It is important to quote "$VALUES_FILE" to ensure line breaks and indentation are preserved
echo "$VALUES_FILE" | helm template -f - | kubeconform -strict

To avoid helm chart installation failure I suggest to follow the following sequence locally or/and in CI pipelines:

• run helm lint. As the docs state:

If the linter encounters things that will cause the chart to fail installation, it will emit [ERROR] messages.

• run helm template for testing whether the chart can be rendered locally successfully. While the installation can still fail once helm->kubernetes api server interaction happens, it still gives good quality check.

• validate that chart's Kubernetes manifests conform to Kubernetes schema using kubeval (doesn't support CRDs) or kubeconform (supports CRDs) after rendering the chart:

helm template [chart_name] . | kubeval

• run helm unit tests for validating that the chart values are as expected (e.g. num of replicas is 1, volume is of type hostPath, etc..):

helm unittest [chart_name] [chart_name]

I summarized how to test helm charts in my blog.

I would high recommend using a combination of the 2 solutions below.

Solution 1

Using a values.schema.json for imposing a structure on the values.yaml file.

Example:

{
  "$schema": "",
  "properties": {
    "image": {
      "description": "Container Image",
      "properties": {
        "repo": {
          "type": "string"
        },
        "tag": {
          "type": "string"
        }
      },
      "type": "object"
    },
    "name": {
      "description": "Service name",
      "type": "string"
    },
    "port": {
      "description": "Port",
      "minimum": 0,
      "type": "integer"
    },
    "protocol": {
      "type": "string"
    }
  },
  "required": [
    "protocol",
    "port"
  ],
  "title": "Values",
  "type": "object"
}

(!) This schema will be applied to the values to validate it. Validation occurs when any of the following commands are invoked:

helm install
helm upgrade
helm lint
helm template

In order to add conditions to the validation - read in here.

(*) Further reading: Nice article.

Solution 2

There are cases when the code in values.schema.json might be less readable when using conditions or we want to use a more dynamic logic into our validation.

In this case, we can create an validations.yaml file (some vendors prefer using a .tpl file) and add the validation logic using go templates.

Example:

If a specific feature (when enabled) needs an ip or a dns:

  some_feature:
    enabled: true
    ip:
    dns:

The validation logic can be written explicitly:

{{- if .Values.some_feature.enabled -}}
    {{- if and (not .Values.some_feature.ip ) (not .Values.some_feature.dns  ) -}}
        When some_feature is enabled, ip or dns must be given.
    {{- end -}}
{{- end -}}

(*) This logic could also be writen using json-schema if-else statement, but it might be less readable.

(**) Consider placing all validations under a /tests or /validations folder where all tests are devided into seperated files (like unit tests).
