Vhdl _ To_Integer
I'm Confused About a Problem I Have in Vhdl. I Make One Vga_Display_ Characters, So I Wanna Convert Some Std_Logic_Vectors into Integer by To_Integer Unsigned...
I'm confused about a problem I have in VHDL.
I make one VGA_display_ characters, so I wanna convert some std_logic_vectors into integer by to_integer unsigned, then I wanna recuperate,
in this way I can't use those libraries in the same time.
ieee.std_logic_arith.all and ieee.numeric_std.all
The error given by quartus:
(Error (10621): VHDL Use Clause error at interface.vhd(34): more than one Use Clause imports a declaration of simple name "unsigned" -- none of the declarations are directly visible Error (10784): HDL error at syn_arit.vhd(26): see declaration for object "unsigned" bellow my code :
1 Answer
My advice is: don't use ieee.std_logic_arith. It's proprietary (not officially part of VHDL) and causes far, far more problems than it solves.
Use only numeric_std and you can do everything you need:
to_integer(unsigned(X)) and to_integer(signed(X)), where X is an std_logic_vector.
To convert back in the other direction:
std_logic_vector(to_unsigned(K, N)) and std_logic_vector(to_signed(K, N)) where K is the integer to convert and N is the number of bits.
