Webservicetransportexception: Not Found [404]

Question

I'm currently implementing a spring web service using jaxb. But when I trying to consume the web service created a WebServiceTransportException: Not Found [404] error is encountered. I did try to search the net but could not able to find a possible root cause. Below I have show my source codes.

application-context.xml

<bean
    class="org.springframework.ws.server.endpoint.adapter.GenericMarshallingMethodEndpointAdapter">
    <constructor-arg ref="marshaller" />
</bean>

<bean id="marshaller" class="org.springframework.oxm.jaxb.Jaxb2Marshaller">
    <property name="classesToBeBound">
        <list>
            <value>com.ph.domain.EightBallRequest</value>
            <value>com.ph.domain.EightBallResponse</value>
        </list>
    </property>
</bean>

<bean id="viewResolver" class="org.springframework.web.servlet.view.InternalResourceViewResolver">
    <property name="prefix">
        <value>/jsp/</value>
    </property>
    <property name="suffix">
        <value>.jsp</value>
    </property>
</bean>

<bean id="simpleUrlHandlerMapping"
    class="org.springframework.web.servlet.handler.SimpleUrlHandlerMapping"
    lazy-init="true">
    <property name="mappings">
        <props>
            <prop key="/test.asp">LandingController</prop>
        </props>
    </property>
</bean>

<bean name="LandingController" class="com.ph.controller.LandingController">
    <property name="stub" ref="eightBallClient"/>
</bean>

Client for webservice

public class EightBallClient extends WebServiceGatewaySupport {

private Resource request;

public void setRequest(Resource request) {
    this.request = request;
}

public String AskQuestion(String question) throws IOException {
    String responseString = null;

    EightBallRequest request = new EightBallRequest();
    request.setQuestion(question);

    EightBallResponse response = new EightBallResponse();

    response = (EightBallResponse) getWebServiceTemplate()
            .marshalSendAndReceive(request);
    responseString = response.getAnswer().toString();
    return responseString;
}
}

definition of my web service

<bean id="schema" class="org.springframework.xml.xsd.SimpleXsdSchema">
    <property name="xsd" value="/WEB-INF/eightball.xsd" />
</bean>

And below is the error stack:

SEVERE: Servlet.service() for servlet dispatcher threw exception
org.springframework.ws.client.WebServiceTransportException: Not Found [404]
    at org.springframework.ws.client.core.WebServiceTemplate.handleError(WebServiceTemplate.java:626)
    at org.springframework.ws.client.core.WebServiceTemplate.doSendAndReceive(WebServiceTemplate.java:550)
    at org.springframework.ws.client.core.WebServiceTemplate.sendAndReceive(WebServiceTemplate.java:501)
    at org.springframework.ws.client.core.WebServiceTemplate.marshalSendAndReceive(WebServiceTemplate.java:350)
    at org.springframework.ws.client.core.WebServiceTemplate.marshalSendAndReceive(WebServiceTemplate.java:344)
    at org.springframework.ws.client.core.WebServiceTemplate.marshalSendAndReceive(WebServiceTemplate.java:336)

Answer 1

Maybe your URI:

 <bean name="webserviceTemplate"
 class="org.springframework.ws.client.core.WebServiceTemplate">
     <property name="defaultUri" value="" />

Check this value:

""

Answer 2

Here is how I resolved this error:

Declare a SoapActionCallback.

Use this callback in the marshalSendAndReceive() as follows.

final EightBallResponse response = new EightBallResponse();
final SoapActionCallback soapActionCallback = new SoapActionCallback("<the operation name as defined in the WSDL>");
response = (EightBallResponse) getWebServiceTemplate()
    .marshalSendAndReceive(request, soapActionCallback );
responseString = response.getAnswer().toString();

Answer 3

In my case, the solution was to pay attention to the case in the URI. I had it in all lower case, but the webservice was expecting a CamelCase action name.
