What Does 24V Common Mean
The C Wire Is Simply the “Common” Side of the Transformer 24V Output (There Are Two Wires Coming out of the 24V Transformer, “Hot” and “Common”). Just Tap into...
The C wire is simply the “common” side of the transformer 24V output (there are two wires coming out of the 24V transformer, “hot” and “common”). Just tap into the “common”. The R (red) wire is really the power source. The C wire closes the circuit and allows continuous flow of 24V energy to power the thermostat.
What is the HUM wire on thermostat?
This configuration allows the humidifier to run whenever the fan switch is set to ON at the thermostat or when the blower operates for some electric heat pump applications. This configuration allows the humidifier to run whenever there is a call for heat. Make sure the “HUM” terminal is 24 volts and not 120 volts.
What is a 24V common wire?
The C-Wire, or “common wire” enables the continuous flow of 24 VAC power to the thermostat. It’s a wire that (if you have one) runs all the way from your furnace to your thermostat. … This bundle green, blue, yellow, white, and red color wires is known as “5 conductor” wire and it is a common type of thermostat wiring.
