What Does a Sub Assembly Print Represent?

A "sub-assembly" drawing provides details about individually assembled components within a larger project or part.

What is a sub assembly drawing?

An assembly drawing shows how each part of a design is put together. If the design depicted is only part of the total assembly, it is referred to as a subassembly. Assembly may consist both of individual original & standard components and of subassemblies of the 1st level.

What are sub assemblies used for?

Sub-assemblies are a series of parts that are combined to form a unique component. Sub-assemblies can be combined to make a larger assembly used on production lines or in service applications.
