What Does Fresnels Do?

A Fresnel lantern (pronounced frəˈnɛl or fruh-nel) is a common lantern used in theatre, which employs a Fresnel lens

Fresnel lens
In many cases they are very thin and flat, almost flexible, with thicknesses in the 1 to 5 mm (1⁄32 to 3⁄16 in) range. Most modern Fresnel lenses consist only of refractive elements.
› wiki › Fresnel_lens
to wash light over an area of the stage. The lens produces a wider, soft-edged beam of light, which is commonly used for back light and top light.

What is the purpose of a Fresnel light?

FRESNEL. The Fresnel is a soft-edged spotlight that offers more control over the angle of the beam than a flood light. A Fresnel light's beam is adjustable because you are able to move the lamp and the reflector closer or further away, by using a screw mechanism or a slide.

Must Read

How do Fresnel lights work?

A Fresnel lens creates this bright beam of light using glass prisms set in metal frame. These prisms change the direction that light is traveling in so all the light exits the lens in same direction. The prisms do this by refracting (or bending) light and reflecting it as well.
