What Is a Difference Between a Stage Micrometer and an Ocular Micrometer

The distance between the lines of an ocular micrometer is an arbitrary measurement that only has meaning if the ocular micrometer is calibrated for the objective being used. A stage micrometer, also known as an objective micrometer, has scribed lines on it that are exactly 0.01mm (10 micrometers) apart.

What is stage and ocular micrometer?

A stage micrometer is simply a microscope slide with a scale etched on the surface. A typical micrometer scale is 2 mm long and at least part of it should be etched with divisions of 0.01 mm (10 µm). … Then one ocular division (smallest increment on the scale) = 10 µm at 100 power.

What is the use of ocular micrometer?

An ocular micrometer is a glass disk that fits in a microscope eyepiece that has a ruled scale, which is used to measure the size of magnified objects. The physical length of the marks on the scale depends on the degree of magnification.
