What Is Cabinet Elevation

The ideal upper cabinet height is 54 inches above the floor. That is, the bottom edge of the upper cabinets should sit 54 inches off the ground.

What is the purpose of elevations?

The purpose of an elevation drawing is to show the finished appearance of a given side of the house and furnish vertical height dimensions. Four elevations are customarily drawn, one for each side of the house. The reference point for most elevations is the grade line.

What are millwork elevations?

Elevation. It’s a 2D picturing of looking at an object from the front. For instance, elevation drawing of the wall represents the simple straight look at it.
