What Is Magnetising Reactance?

In circuit theory terms, the magnetising reactance is simply the reactance due to the self-inductance of the primary of the transformer. Its value reflects the magnetising current, as discussed later. ... resembles a transformer with two air-gaps in its magnetic circuit.

What is Magnetising reactance in induction motor?

The magnetizing reactance X₀ in an induction motor will have a much smaller value. In a transformer, I₀ is about 2 to 5% of the rated current while in an induction motor it is approximately 25 to 40% of the rated current depending upon the size of the motor.

What is meant by leakage reactance?

: the part of the reactance of a circuit that corresponds to the leakage flux.
